Gra-Vue MIO-AD-AUD Analog Audio to AES Converter

ITEM #: GFE-MIO-AD-AUD MFG #: MIO AD-AUD

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Gra-Vue Co., Ltd.
Free Shipping with $49 Minimum Order

Our Price:

$303.45

Add to Wish ListLeasing Options
Availability: In Stock
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

MIO AD-AUD - Overview

The MIO-AD-AUD is a miniature Analog to AES digital audio converter. The MIO-AD-AUD Converts four ch. balanced analog audio to two groups of digital audio with broadcast quality 24 bit processing. Output audio group selected by DIP switch.
The MIO AD-AUD requires a 12V DC power from an optional AC to DC power supply or 12V external source, such as a camera or battery. For user confidence and convenience there are two LEDs that indicate the status of source signal and power.

  • Features:

    • Convert four ch. balanced analog audio to two groups of AES digital audio
    • Broadcast quality with 24 bit processing and 48KHz audio sampling
    • Locks to any AES reference from 32-96KHz or free runs at 48KHz
    • Input gain controls to cover all commonly used levels
    • Selectable output Audio group
    • LED indicators for signal source and power


  • Specifications:

    • Analog audio Input:
    • 4 x 3 pin phoenix, 110 Ohm, balanced
    • Frequency response: <±0.25dB(20Hz~20kHz)
    • Max level: +24dBu
      Digital audio Output:
    • 2 x BNC, 75 Ohm, balanced
      LED Status Indication:
    • Power & Input signal locking
    • Dimension: 124.5 x116.5 x30mm
    • Power: 12VDC 1.0A
    • Working Temp.: 5 °C - 25 °C


  • Item Includes:

    • 12VDC power adapter, 4 x 3 pin pheonix male connectors
