JBL SRX812P 2000 Watt Powered 2-way system featuring Crown Amplification

ITEM #: JBL-SRX812P MFG #: SRX812P

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$2,083.88

Our Price:

$1,669.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    SRX812P - Overview

    12" Two-Way Bass Reflex Self-Powered System

    The SRX800 Series is the next generation high performance powered loudspeaker system comprising three full range and two subwoofer models with an array of features that elevate the SRX800 Series to the best in class of all competitive systems. The full range 12" two-way, SRX812P features legendary JBL Drivers, proprietary 2,000 Watt Crown amplification, Crown Front-End DriveCore Technology, premium JBL user-configurable DSP, V5 Tunings compatible with Vertec and VTX touring systems, and HiQnet Network control options via iOS and Android applications. Drawing on JBL’s long history of groundbreaking technology and loudspeaker design, the SRX800 Series meets the needs of touring houses, installations, and the most demanding live sound applications ensuring they can deploy a no-compromise, all-in-one solution featuring legendary JBL sound and performance, a wide array of configurability, and compatibility with JBL’s flagship touring systems.

    • Features:

      • Purposeful Design: Rugged, Intuitive to Use, Easy to Transport
      • JBL Premium Transducers
      • Drivecore Amplification By Crown
      • Full User Configurable DSP
      • Network Control
      • JBL Engineered Application Presets
      • LCD Screen and Glow in the Dark Ink on Back Panel
      • M10 Suspension Points
      • Standard 35mm Pole Cup
      • Feet for Monitor Angle

    • Specifications:

      • System
      • System Type: Self powered 12”, two-way, bass-reflex
      • Maximum SPL Output: 136 dB
      • Frequency Range (-10 dB): 40Hz – 21kHz
      • Frequency Response (-3 dB): 48Hz – 20kHz
        Amplifier:
      • System Power Rating: 2000W Peak, 1500W Continuous
      • Input Impedance: 40k balanced, 20k unbalanced
      • Line Input Gain: 21 dB
      • Consumer Input Gain: 33 dB
      • Mic Input Gain: 45 dB
        Maximum Input Level:
      • Line: 20dBu
      • Consumer: 8dBu
      • Mic: -4dBu
      • Connectors: Neutrik ¼ - XLR input; Neutrik XLR Output
      • LED Indicators: Power LED (Green) Network Link (Green) Network Data (Yellow)
      • Cooling: On-Demand variable speed fan
      • AC Power Input: 100V - 240V~ 50/60 Hz
      • AC Power Consumption (120V~): 2.2A (1/8th Power), 5.6A (1/3rd Power)
        Speaker:
      • LF Driver: 2272F
      • HF Driver: 2432H
      • Coverage Pattern: 90 x 50
      • Crossover Frequency: 1.9kHz
        Enclosure:
      • Material: 18mm plywood
      • Monitor Angle: Yes
      • Suspension/Mounting: Dual 36mm pole socket,
      • 12 x M10 Suspension points
      • Handles: 3
      • Finish: Obsidian Duraflex finish
      • Grille: Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing
      • Dimensions (L x W x H): 16.87” x 16.31” x 25.11”
      • Weight: 58.0 lbs.

    • Item Includes:

      • 1 x SRX800 speaker
      • 1 x 10'(3m) IEC Power Cable
      • 1 x Quick Start Guide

    • Warranty:

      • 5 Years

    • GTIN:

      0691991000676
