JVC GY-HC500U CONNECTED CAM 4K HDR Pro Res SSD Handheld Camcorder

ITEM #: JVC-GY-HC500U MFG #: GY-HC500U

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
JVC
Free Shipping with $49 Minimum Order

List Price:

$3,495.00

Our Price:

$3,295.00

After Savings:

$2,795.00

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Eligible for $500 in Instant Savings!Save $500 on the GY-HC500U when you order now. Shop with Markertek today and save BIG!
Report Lower PriceLarge Quantity Quote

GY-HC500U - Overview

The Panasonic GY-HC500U is a handheld 4K production camcorder that offers uncompromised live and recorded image quality, and connectivity you won't find in any competitor's product. Shoot 4K ultra-HD with HDR and record to SSD or SDHC/SDXC media in a wide variety of formats including ProRes. Ultra-HD ProRes 422 10-bit at 50/60p is possible when recording to SDD media.** And with the latest firmware, you can now record HD (1920 x 1080) in the ProRes 422 and 422HQ formats. The GY-HC500 CONNECTED CAM also features high performance 1080 60p/50p live streaming with advanced Secure Reliable Transport (SRT) QoS, and a full complement of IP remote control and viewing features. Now, with the optional KA-EN200G encoder, streaming is possible with incredibly efficient HEVC/H.265 compression. It's truly the most advanced and versatile camcorder in its price range.

Firmware V0201-0206 is available for download.
What's new:
Facebook Live & YouTube Live simple connection
New streaming aspect ratio 9:16 and 1:1
720p Web Proxy REC resolution
Stream ID and FEC at SRT protocol
VITC in streaming Time code system
"Field" interlace format for Live streaming
Auto adjustment of Color matrix under LED lighting
Improved Remote zoom ease function

  • Features:

    • 10-bit ProRes 422/422HQ/422LT, at 4K UHD resolution and 59.94p/50p/29.97p/25p/23.98p recording to M.2 SSD**
    • 4K UHD 29.97p/25p/23.98p 4:2:2 10-bit or 4:2:0 8-bit (150Mbps) and various HD recording to SDHC/SDXC card*
    • HDR recording, HLG or J-Log1 (10-bit)
    • Backup recording to SSD (v0110)**
    • Clip Continuous Record mode
    • 1-inch (effective) CMOS sensor with high picture quality
    • F11 Sensitivity
    • Newly-developed 3-ring 4K lens with 20x zoom (f=28mm-560mm 35mm equivalent)
    • 40x lossless dynamic zoom
    • 4-inch high resolution LCD monitor
    • LCOS Quad VGA viewfinder
    • XLR audio connectors
    • High performance 1080 60p/50p live streaming (4K Rec + HD streaming + 4K HDMI output)
    • Secure Reliable Transport (SRT) QoS for reliable, quality streaming (v0110)
    • Facebook Live streaming with secure RTMPS protocol (v0110)
    • Low latency and high-quality streaming up to 20Mbps with SMPTE 2022 Forward Error Correction
    • LAN terminal (Streaming/IFB/Remote) in addition to USB host (v3.0)
    • HEVC/H.265 encoding for streaming with 50% reduction in bit rate-or-contribution quality 4:2:2 10-bit streaming at up to 24Mbps (via optonal KA-EN200G)
    • Return over IP (Return video and IFB)
    • Auto FTP to upload native video clips automatically


  • Specifications:

    • Power: DC12V (AC adapter), DC7.2V (battery).
    • Power Consumption: Approx. 17.5W.
    • Weight: 3.1kg (with hood and battery, without wireless LAN antenna unit).
    • Moisture Protection: IPX2 equivalent.
    • Image Sensor: 1" (effective) CMOS, effective number of pixels: approx 9.35 million.
    • Stabilizer: Optical image stabilizer.
    • Sensitivity: F11 at 2000lx 89.9% reflectance.
    • Lens: F2.8 (wide) to F4.5 (tele), f=9.43mm to 188.6mm (f=28mm to 560mm (35mm equivalent).
    • Filter Diameter: 82mm
    • Shutter Speed: 1/6 to 1/10000.
    • ND Filter: Off, 1/4, 1/16, 1/64.
    • Viewfinder: 0.4" LCOS Quad VGA (1280 x 960), 1280 x 720 at 16:9.
    • LCD Monitor: 3.97" LCD /WVGA (800 x 480), 800 x 450 at 16:9.
    • Recording Media: SDHC/SDXC memory card x 2: 4K (150Mbps): UHS-1 U3, 4K (70Mbps)/HD (50Mbps): Class 10, HD (35Mbps): Class 6, SD: Class 4, High-Speed: UHS-1 U3, SSD (M.2) with optional media case by JVC.
    • Video Codec: Apple:ProRes 422, MPEG-4 AVC/H.264 (HD/SD), MPEG-2 (HD)*.
    • File Format: MOV,MP4.
    • Recording Modes:
      4K UHD: 60p/50p 3840x2160, Apple ProRes 422 HQ / Apple ProRes 422 / Apple ProRes 422 LT, 10-bit.
      4K UHD: 30p/25p/24p: 3840x2160, 4:2:2 10-bit / 4:2:0 8-bit 150Mbps / 70Mbps (H.264).
      HD (H.264): 1920x1080 / 1280x720, 4:2:2 10-bit / 4:2:0 8-bit mode, etc., 50Mbps -8Mbps.
      SD (H.264): 720 x 480 (U model)/720 x 576 (E/EU model), 8Mbps.
    • Proxy (H.264): 960 x 540/480 x 270, 3 - 1.2Mbps.
    • Audio Recording: LPCM 2ch, 48kHz/16-bit (MOV), æ-Law 2ch (Proxy), AAC 2ch (MP4).
    • Protocol: RTMP, MPEG2-TS/UDP, MPEG2-TS/TCP, MPEG2-TS/RTP, RTSP/RTP.
    • Resolution and Bit Rate: 1920 x 1080 (59.94p/50p) 20 - 8Mbps, (29.97p/25p) 20 - 3Mbps, 1920 x 1080 (59.94i/50i) 20 - 3Mbps, 1280 x 720 (59.94p/50p) 20 - 3Mbps, 1280 x 720 (29.97p/25p) 8 - 1.5Mbps, 640 x 360 (59.94p/50p) 3/1.5Mbps, 640 x 360 (29.97p/25p) 3 -0.3Mbps.
    • Video Output: 3G-SDI output (BNC x 1), HDMI output x 1, AV output (3.5mm mini jack x 1).
    • Audio Input: XLR x 2 (MIC, +48V/LINE), 3.5mm mini jack x 1
    • Audio Output: AV output (o3.5mm mini jack x 1).
    • Headphone: 3.5mm mini jack x 1.
    • Remote: 2.5mm mini jack x 1
    • Time Code Input/output: RCA
    • USB: HOST x 1 (network connection).
    • Ethernet: RJ-45 x 1.
    • Built-in Slot: Optional SSD media case and for future expansion.


  • Item Includes:

    • 1x JVC GY-HC500U Connected Cam 4K Handheld Camcorder
    • 1x Battery (BN-VC264)
    • 1x AC adapter
    • 1x Power cable
    • 1x Lens hood
    • 2x Wireless LAN antenna


  • GTIN:

    0046838079702
