Kramer 613R/T 3G SDI Rx/Tx Extender over Ultra-Reach SM Fiber

613R/T - Overview

HDTV Compatible

• Features:

  • Maximum Data Rate - Up to 3Gbps.
  • HDTV Compatible.
  • Multi-Standard Operation - SDI (SMPTE 259M and SMPTE 344M), HD-SDI (SMPTE 292M), 3G HD-SDI (SMPTE 424M) & DVB-ASI.
  • Laser Standards Compliance - IEC 60825-1, FDA 21CFR1040; Laser Class 1: Safety of laser products.
  • Kramer Equalization & re-Klocking™ Technology - Rebuilds the digital signal to travel longer distances.
  • System Range - Up to 30km (18.6mi) at 3G-HD-SDI (1080p).
  • Fiber Cable - Single-mode fiber optic with ST connectors.
  • Compact Size - Part of the Kramer TOOLS™ family of compact, high-quality and cost-effective solutions.


• Specifications:

  • INPUTS: 1 SD/HD/3G HD-SDI, 75? on a BNC connector (613T); 1 ST optical connector (613R).
  • OUTPUTS: 1 ST optical connector (613T); 1 SD/HD/3G HD-SDI, 75Ω on a BNC connector (613R).
  • MAX. DATA RATE: Up to 3Gbps.
  • MAXIMUM RANGE: 30km (18.6 Miles) @1080p, 3G-SDI format.
  • FORMAT: SMPTE 424M (3G HD-SDI); SMPTE 292M (HD-SDI); SMPTE 259M (SDI, DVB-ASI).
  • RESOLUTION: Up to WUXGA @60Hz (1.65Gbps).
  • POWER CONSUMPTION: 5V DC, 1.5A.
  • OPERATING TEMPERATURE: -20° to +70°C (-4° to 158°F).
  • STORAGE TEMPERATURE: -30° to 85°C (-22° to 185°F) ambient.
  • HUMIDITY: 5% to 95% RH.
  • DIMENSIONS: 1.9cm x 8.3cm x 1.9cm (0.75" x 3.3" x 0.75") W, D, H.
  • WEIGHT: 0.1kg (0.2lbs) approx.
  • INCLUDED ACCESSORIES: 2 power supplies.


• Item Includes:

  • 613 Transmitter and Receiver Pair
  • 5V DC Power Supply (2)
