Kramer Galil-2-C 2.5 Inch Closed-Back 2-Way Ceiling Speaker - EN 54-24 Certified

GALIL-2-C - Overview

Full-Range Closed-Back Ceiling Speaker

• Features:

  • Type - Closed-back ceiling speaker
  • Woofer - 2.5" paper cone
  • Impedance - 8Ω (transformer tap in off position)
  • Power Handling - 10W RMS, 30W continuous program
  • Transformer Taps - 70V - 3W/1.5W/0.75W/8Ω/10W/Off (Lo-Z); 100V - 6W/3W/1.5W/8Ω/10W, Off (Lo-Z)


• Specifications:

  • DESCRIPTION
  • Full-range closed-back ceiling speaker


  • FREQUENCY RESPONSE
  • 90Hz to 20kHz @-15dB, 150Hz to 20kHz @-3dB


  • WOOFER
  • 2.5" (68mm) paper cone with rubber surround


  • IMPEDANCE
  • 8Ω (transformer tap in off position)


  • TRANSFORMER TAPS
  • 70V - 3W/1.5W/0.75W/8Ω/10W/Off (Lo-Z)
  • 100V - 6W/3W/1.5W/8Ω/10W, Off (Lo-Z)


  • SENSITIVITY
  • 69dB SPL, 10W@4m


  • MAX SPL
  • Continuous: 79.3dB SPL, 10W@4m


  • POWER HANDLING
  • 10W RMS, 30W continuous program


  • DIRECTIVITY FACTOR (Q)
  • 3.7, averaged 1kHz to 10kHz


  • DIRECTIVITY INDEX (DI)
  • 5.7dB averaged 1kHz to 10kHz


  • COVERAGE ANGLE @-6DB
  • 500Hz-240°, 1kHz-160°, 2kHz-110°, 4kHz-105°


  • INPUT CONNECTOR
  • Ceramic terminals


  • ENCLOSURE PROTECTION DEGREE
  • IP21C


  • MATERIALS
  • Frame, aluminum grill, safety cord attached to grill, plastic back-can (self-extinguishing ABS according to UL94 V-0)


  • OPERATING TEMPERATURE
  • -10° to +55°C (14° to 131°F)


  • STORAGE TEMPERATURE
  • -40° to +70°C (-40° to 158°F)


  • HUMIDITY
  • 10% to 90%, RHL non-condensing


  • WEIGHT PER SINGLE SPEAKER
  • 0.5kg (1.1bs)


  • INSTALLATION CLEARANCE
  • Mounting depth: 9.5cm (3.74")


  • CUT-OUT DIAMETER
  • 12.6cm


  • COLORS
  • White


• Item Includes:

  • Galil-2-C Full-Range Closed-back Ceiling Speaker (1)


• Warranty:

  • Standard one (1) year warranty


• GTIN:

  7291063072612
