Lightronics DB612 Distributed Dimming Bar - Black

ITEM #: LGT-DB612 MFG #: DB612

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$1,999.00

Our Price:

$1,499.25

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
  • Shipment of this item is subject to a separate oversized-package carrier surcharge.


DB612 - Overview

Our engineers envisioned the ultimate dimmer bar, a product that offers substantial Savings, Versatility and Reliability.
Utilizing Lightronics DB series Distributed Dimming System, you can save up to 40% on materials and labor during the
installation of your new lighting control system. The DB Series is ideally suited for ALL stage applications including theaters,
schools and churches. It's designed to operate a minimum of 15+ years with a single removable electronics module that contains
all of the electronics for easy swap out.

  • Features:

    • 6 Channels
    • 1200W per Channel
    • DMX-512
    • Mounting Track
    • Fast Acting Magnetic Circuit Breakers
    • Terminal Strip Input
    • Edison Outputs
    • UL-508 Compliant
    • Available in Black or White
    • Also Available in 1400W

  • Specifications:

    • Channels / Capacity: 6 @ 1200 Watts each
    • Semiconductors: 40 Amp 400V Triacs, 300% overhead
    • Power Requirements: 120/240VAC Single Phase, 30 Amps 120/208VAC Three Phase, 20 Amps
    • Control Protocol: USITT DMX-512
    • Filtering: 450 Usec. Minimum
    • Overload Protection: 10 Amp, Fast Acting Magnetic Circuit Breaker for each Channel
    • Addressing: Starting channel can be set to any of 512 channels
    • Local Control: On board test buttons for each channel
    • Relay Mode: Switchable by Individual Channel
    • Output Panel Options: Edison Plugs, 20 Amp Stagepin Panels, 20 Amp Twistlock Panels
    • Size: 72”L x 5”W x 3”D
    • Weight: 26 Pounds
