Lilliput BM150-4K 15.6 Inch Carry-on/Rackable 4K Broadcast Director Monitor with SDI HDMI VGA & DVI Inputs V-mount

BM150-4K-VBP - Overview

• Features:

  • 4K (3840*2160) Ultra-HD Native Resolution
  • 15.6" Perfect Size For Both Suitcase & Rackmount
  • High Contrast: 1000:1
  • 330cd/m² Brightness
  • 176° Ultra High Viewing Angle
  • Abundant Interfaces: 3G-SDI, HDMI, VGA, AV input
  • Metal Housing
  • Wide Voltage: DC12-24V


• Specifications:

  • Display
  • Display Screen: 15.6" 8 bit
  • Physical Resolution: 3840x2160, 4K
  • Aspect Ratio: 16:9
  • Brightness: 330cd/m²
  • Contrast: 1000:1
  • Viewing Angle: 176°/176°(H/V)

    Input
  • 3G-SDI: 1
  • Wireless HDMI: 1 (optional)
  • HDMI: 2.0x1 (4K@60Hz)
  • HDMI: 1.4x3 (4K@30Hz)
  • DVI: 1
  • VGA: 1
  • Audio: 2 (L/R)
  • TALLY: 1
  • OUTPUT: 3G-SDI - 1

    Audio
  • Speaker: 1
  • Ear Phone Slot: 1

    Power
  • Current: 1A (15V)
  • Input Voltage: DC 12-24V (XLR)
  • Battery Plate: V-mount / Anton Bauer mount
  • Power Consumption: ≤15W

    Environment
  • Operating Temperature: 32° to 140°F (0° to 60°C)
  • Storage Temperature: -4° to 140°F (-20° to 60°C)

    Dimension
  • Dimension(LxWxD): 15.32 x 10.51 x 1.50" (389 x 267 x 38mm)
  • Dimension (with case)(LxWxD): 20.63 x 12.01 x 6.69" (524 x 305 x 170mm)
  • Weight: 7.50 lbs (3.4kg)
  • Weight (with case): 26.45 lbs (12kg)

    SDI Format
  • SMPTE-125M
    480i(59.94)
    1080i(60/59.94/50)
    1080p(30/29/97/25/24/24sF/23.98/23.98sF)
  • SMPTE-292M
    1080p(30/29/97/25/24/24sF/23.98/23.98sF)
  • SMPTE-296M
    720p(60/59.94/50/30/29/25/24/23.98)
  • SMPTE-372M
    720p(60/59.94/50)
    1080i(29.97/25/24/23.98)
    1080p(60/59.94/50/30/29/25/24/23.98)
  • SMPTE-425M-AB
    1080p(60/59.94/50)
  • Level A & Level B
    720p(60/59.94/50/30/29/25/24/23.98)
  • Level B 2x
    1080i(60/59.94/50)
    ITU-R BT.656
    576i(50)
  • HDMI Format
    4k, 1080p, 1080i, 1035i, 720p, 576p, 576i, 480p, 486i


• Warranty:

  • 1 year parts and labor


• GTIN:

  0695082160157
