NTI 4K-HD-SCALER NTI 4K HDMI Up/Down Scaler with Audio Extractor and HDCP 2.2 Converter

4K-HD-SCALE - Overview

• Features:

  • Up-scale 1080p to UHD 4K (3840x2160) up to 4:4:4 @60Hz - change an HD device like a Blu-ray player or cable box into a 4K video source
  • Down-scale 4K (4096x2160 or 3840x2160) to 1080p - view video from a 4K source on an HD screen
  • Supported frame rates: 24/25/30/50/60Hz
  • Does not support frame conversion - input and output must support the same frame rate
  • HDMI features supported:
    HDMI 2.0 compliant
    x.v.Color, sYCC601 color, Adobe RGB Color and Adobe YCC601 color
    Dolby TrueHD, DTS-HD Master Audio, Dolby Digital, and DTS
    Bandwidth up to 18 Gbps
    Support for CEC (consumer electronic control) compatible devices
    3D
    Lip Sync
  • HDCP 1.4 and 2.2 compliant: Built-in HDCP 2.2 to HDCP 1.4 converter - play video from an HDCP 2.2 source on an HDCP 1.4 4K display
  • Extracts audio from HDMI input and outputs with 3.5mm stereo audio jack or Toslink
  • Supports HDMI cables up to 50 feet
  • Bypass non 1080p and 4K resolutions
  • Front panel EDID configuration button
  • Ideal for use with switches, splitters, matrixes, and any other application needing to accommodate both HD and 4K sources and displays


• Specifications:

  • Connectors
  • Female HDMI input/output connectors
  • One 3.5mm stereo audio output jack
  • One digital optical S/PDIF TOSLINK audio output jack

    Video
  • Input resolution: 480i to 4Kx2K (4096 x 2160 or 3840 x 2160)
  • Output resolution: 480i to 4Kx2K (3840 x 2160)
  • Supported frame rates: 24/25/30/50/60Hz (Does not support frame conversion - input and output must support the same frame rate)
  • Signal rate: 18 Gbps
  • HDMI 2.0 (up to 4K@60Hz 4:4:4) compliant
  • HDCP 1.4 and 2.2 compliant

    Dimensions (WxDxH)
  • 5.63 x 3.26 x 1.02" (143 x 83 x 26mm)

    Power
  • Input: 110 or 220 VAC at 50 or 60Hz via AC adapter (US AC adapter included)
  • Optional universal power plug adapters available (not included)
  • Output: 5VDC, 1.5A
  • Power consumption: 3W

    Environmental
  • Operating temperature: 32 to 104°F (0 to 40°C)
  • Storage temperature: -4 to 140°F (-20 to 60°C)

    Cables
  • Use HD-xx-MM cable to connect an HDMI source or display
  • Max HDMI cable length: 50 feet
  • Note: Cables not included


• Warranty:

  • 2 Year Warranty
