FTAD2-A010 - Overview

Ophit FTAD2 is a detachable AOC (Active Optical Cable) for DisplayPort standard. The FTAD2 consists of a transmitting and receiving parts, both of which are connected by a hybrid cable (Optical cable + electric cable). The FTAD's transmitter is connected to the Display Port source device, and the receiver is connected to the DisplayPort sink device. The mini-Displayport connector can also be used by connecting each source and sink device. With FTAD2, Video/audio signals can be transmitted up to 328 feet (100m) when a system using DisplayPort standard is used. It is possible to transmit the DisplayPort specification signal of the UHD bandwidth without loss.

  • Features:

    • High speed and long-distance transmission by optical system
    • Input and Output Signal: DisplayPort 1.2a/1.4 Standard by VESA
    • MMF optical fiber + copper hybrid cable structure
    • DPCD/HDCP compliant
    • AUX and Hot Plug channels are transmitted by copper line
    • Maximum transmission distance: 328ft/100m
    • Connector: DisplayPort 20pin (Male) or Mini-DisplayPort Plug
    • Mini-DisplayPort (Source) to Mini-DisplayPort (Display) connectivity is possible
    • No external power supply required


  • Specifications:

    • Transmitter Connector: DisplayPort 20pin (male) or Mini-DisplayPort Plug
    • Receiver Connector: DisplayPort 20pin (male) or Mini-DisplayPort Plug
    • Length: 32.8ft (10m)
    • Applied Fiber: 50/125æm Multi-mode glass-fiber
    • Video Bandwidth: 32.4Gbps (HBR3)
    • Supporting Resolution & Distance: 7680x4320 @60Hz/328ft (100m)
    • Transmitter Power Consumption: 0.122W (Typ)
    • Receiver Power Consumption: 0.264W (Typ)
    • Module Dimensions: 2.61" x 0.77" x 0.47" (66.5mm x 19.8mm x 11.9mm)
    • Operating Temperature Range: 32°F - 122°F (0°C - 50°C)
    • Storage Temperature Range: -4°F - 158°F (-20°C - 70°C)


  • Item Includes:

    • 1x Ophit FTAD2 8K DisplayPort 1.2a/1.4 Detachable 32.4 Gbp Active Optical Cable - 32.8 Feet/10 Meters
