Peerless-AV SUA747PU 32 to 50 Inch Universal Ultra Slim Articulating Wall Mount

SUA747PU - Overview

• Features:

  • The I-Shaped Adaptor plate's innovative design helps avoid blocking connections on back of display
  • Internal cable management provides clean, professional installation finish
  • Universal mount fits displays with mounting patterns 200 x 100 to 400 x 400mm
  • Landscape or portrait mounting options increases display versatility
  • Arm retracts to 1.85" (47mm) and extends up to 24.85" (631mm) from wall
  • One-Touch tilt mechanism allows adjustment of +15/-5° without the use of tools
  • Up to ±90° of side-to-side swivel
  • Added ±5 of roll for postinstallation display leveling without the use of tools
  • Up to ±0.5" (13mm) of vertical adjustment for post-installation leveling and height adjustment fine-tuning


• Specifications:

  • Color Black
  • Finish High Gloss
  • Distance from Ceiling N/a" (N/amm)
  • Distance from Wall 1.85 - 24.85" (47 - 631mm)
  • Increlock Increments N/a
  • Mounting Pattern 400 x 400mm (15.75 x 15.75")
  • Roll +/-5
  • Minimum to Maximum Screen Size 32" to 50"
  • Security Features Non-Security Hardware
  • Swivel Yaw +/-90
  • Tilt +5/-15
  • VESA Pattern 200 x 100, 200, 300 x 200, 300, 400 x 200, 400 x 300, 400
  • Weight Capacity 60lb (27kg)
  • Product Dimensions 16.94x20.25x1.85-24.85" (430x514x47x631mm)
  • Shipping Weight 15.33lb (0kg)
  • Ship Dimensions 19.5 x 3.25 x 21.25" (495.3 x 82.6 x 539.8mm)


• Warranty:

  • Limited 5-Year


• GTIN:

  0735029306382
