RME HDSPe AIO Pro 24 Bit 192 kHz PCI Express Card 30-channel - Analog - ADAT - SPDIF & AES/EBU

HDSPE AIO PRO - Overview

• Features:

  • All settings can be changed in real-time
  • Analog, ADAT and SPDIF I/Os can be used simultaneously
  • AES and SPDIF I/Os can be used simultaneously
  • Buffer sizes/latencies from 32 up to 8192 samples selectable
  • 4 channels 96 kHz/24 bit record/playback via ADAT optical (S/MUX)
  • 2 channels 192 kHz/24 bit Record/Playback via ADAT optical (S/MUX4)
  • Automatic and intelligent master/slave clock control
  • Unsurpassed Bitclock PLL (audio synchronization) in ADAT mode
  • SteadyClock FS: Jitter-immune, super-stable digital clock
  • DDS technology for free setting of the sample rate
  • TotalMix for latency-free submixes and perfect ASIO Direct Monitoring
  • TotalMix: 448 channel mixer with 46 bit internal resolution
  • SyncCheck tests and reports the synchronization status of input signals
  • 1 x MIDI I/O, 16 channels high-speed MIDI
  • DIGICheck DSP: Level meter in hardware, peak- and RMS calculation
  • 1 x stereo analog Line In with 4 hardware reference levels
  • 1 x stereo analog Line Out with 4 hardware reference levels
  • 1 x stereo analog Line/Headphone Out, separate output for independent submix
  • Powerful High Power² phones output with switchable High/Low mode
  • Optional Time Code module (TCO) for external Video-/SMPTE synchronization
  • Optional Word Clock Module for word clock input and output


• Item Includes:

  • 1x HDSPe AIO Pro PCI Express card
  • 1x Quick Info guide
  • 1x Digital adapter cable (phono / XLR to D-sub 9-pin)
  • 1x Analog adapter cable (phono / phono / TRS / MIDI to D-sub 15-pin)
  • 1x Internal cable (3-core)
  • 1x Optical cable (TOSLINK)
