Shure ULXD1-V50 Dual Digital Wireless Bodypack Transmitter with Miniature 4-Pin Connector - V50 - (174-216 MHz)

ITEM #: SH-ULXD1-V50 MFG #: ULXD1-V50

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$794.00

Our Price:

$567.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


ULXD1-V50 - Overview

The ULXD1 Wireless Bodypack Transmitter by Shure is for capturing audio. It can be used in various environments, when paired with a ULXD4 receiver for applications such as, theater, stage, broadcast TV, DJ setups, and more. The ULXD1 compact bodypack transmitter is enclosed in a rugged metal housing with a TA4-M (4-pin male) audio input connector and features a comprehensive LCD display.

The ULXD1 features pristine, compandor-free digital transmission for uncompromising sound quality, range and detail. Its 256-bit encryption keeps wireless transmissions secure, and its adjustable RF output power delivers maximum range wherever necessary. The ULXD1 operates on either alkaline AA batteries or Li-Ion rechargeable batteries for up to 12 hours.

Please Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.

  • Features:

    • AES 256-bit encryption for applications requiring secure data transmission
    • Proprietary Shure Gain Ranging optimizes the system's dynamic range for any input source, eliminating the need for transmitter gain adjustments
    • Optional Shure SB900A lithium-ion rechargeable battery provides over 11 hours of battery life, precision metering in hours and minutes, and zero memory effect
    • External charging contacts for docked charging (with the SBC200 Dual Docking Charger)
    • Backlit LCD with easy to navigate menu and controls
    • Rugged metal construction
    • Detachable ¬ wave antenna
    • Frequency and power lockout

  • Specifications:

    • Mic Offset Range: 0 to 21 dB (in 3 dB steps)
    • Audio Frequency Response: 20 - 20 kHz (±1 dB)
    • Battery Type: Shure SB900B Rechargeable Li-Ion or LR6 AA batteries 1.5 V
    • Battery Runtime: @ 10 mW
    • Dimensions: 86 mm x 66 mm x 23 mm (3.4 in. x 2.6 in. x 0.9 in.) H x W x D
    • Weight: 142 g (5.0 oz.), without batteries
    • Housing: Cast aluminum
    • Audio Input Connector: 4-Pin male mini connector (TA4M), See drawing for details
    • Configuration: Unbalanced
    • Impedance: 1 MΩ, See drawing for details
    • Maximum Input Level: 1 kHz at 1% THD
    • Preamplifier Equivalent Input Noise (EIN): System Gain Setting = +20-120 dBV, A-weighted, typical
    • RF Output Connector: SMA
    • Antenna Type: 1/4 wave
    • Impedance: 50 Ω
    • Occupied Bandwidth: <200 kHz
    • Modulation Type: Shure proprietary digital
    • Power: 1 mW, 10 mW, 20 mW

  • GTIN:

    0042406462785
