Tripp Lite Smart1500RM2U Rack Mount UPS System 8 Outlet 2 RU

ITEM #: SMART1500RM2U MFG #: SMART1500RM2U

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$1,304.78

Our Price:

$780.00

Availability: In Stock
iAvailability Description Popup


    SMART1500RM2U - Overview

    The Tripp Lite SMART1500RM2U SmartPro 120V 1.5kVA 1.35kW Line-Interactive Sine Wave UPS provides battery backup and AC power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. Ideal for backing up servers and network storage devices, the SMART1500RM2U switches to battery mode in milliseconds to keep your connected equipment running long enough to save files and shut down safely with no data loss.

    Featuring eight NEMA 5-15R outlets(four switchable) and a 10-foot power cord with 120V NEMA 5-15P input, the SMART1500RM2U has an internal battery that provides 13 minutes of support at half load and 4.5 minutes at full load. A front-panel LCD screen lets you monitor important data, such as load level, voltage, battery charge and estimated runtimes.

    Automatic voltage regulation(AVR) maintains 120V nominal output over an input range of 83V to 147V without using battery power. EMI/RFI noise filtering improves your equipment's performance and prevents damage. A 570-joule surge suppression rating protects your equipment from harmful power surges. With Tripp Lite's included PowerAlertr software, the SMART1500RM2U enables safe unattended system shutdown and file saves in case of a prolonged power failure. Adding an optional Network Management Card, such as Tripp Lite's SNMPWEBCARD, permits remote management of the UPS, including reboots and activity logs.

    • Features:

      • Provides fully regulated sine wave AC output for servers, network storage devices and telecom hardware.
      • Audible alarm signals loss of utility power, overload, low battery and fault conditions.
      • 8 NEMA 5-15R outlets.
      • 10 ft. power cord with 120V NEMA 5-15P input.
      • 0.9 power factor rating.
      • 570-joule surge suppression rating.
      • Supports half load up to 13 min. and full load up to 4.5 min.
      • Internal batteries designed for hot-swap field replacement.
      • 95% line-power efficiency rating saves money in energy costs.
      • Can control 4 outlets remotely to reboot equipment or shed nonessential loads.
      • Maintains 120V nominal output over input range of 83V-147V without using battery power.
      • Removes electromagnetic and radio frequency interference that can disrupt or damage equipment's performance.
      • Front-panel LCD signals operating mode, load level, voltage, battery charge and estimated runtimes.
      • Rotates for easy viewing in rack-mount or tower configurations.
      • Optional Network Management Cards, such as Tripp Lite's SNMPWEBCARD, permits remote management of UPS, including reboots, configuration, updates and activity logs.
      • USB and DB9 ports combine with included PowerAlert software to monitor operating conditions, monitor AC power, and enable safe unattended system shutdown and file saves in case of a prolonged power failure.
      • EPO port supports emergency shutdown in large facilities.
      • Hardware included for 4-post mounting in 2U of EIA-standard 19 in. rack.
      • Mounts on wall or 2-post rack with optional 2POSTRMKITWM accessory.
      • Mounts in upright tower position with optional 2-9USTAND accessory.

    • Specifications:

      • Output:
      • Output Volt Amp Capacity (VA): 1500
      • Output kVA Capacity (kVA): 1.5
      • Output Watt Capacity (Watts): 1350
      • Output kW Capacity (kW): 1.35
      • Power Factor: 0.9
      • Nominal Voltage Details: 120v nominal output in battery mode
      • Frequency Compatibility: 60 Hz
      • Output Voltage Regulation (Line Mode): -21%, +8%
      • Output Voltage Regulation (Battery Mode): +/- 5%
      • Load Management Receptacles: Two switchable two-outlet 5-15R load banks
      • Output AC Waveform (AC Mode): Sine wave
      • Output AC Waveform (Battery Mode): Pure Sine wave
      • Nominal Output Voltage(s) Supported: 110V; 115V; 120V
      • Output Receptacles: (8) 5-15R
      • Individually Controllable Load Banks: Yes

      • Input:
      • Rated input current (Maximum Load): 12A
      • Nominal Input Voltage(s) Supported: 120V AC
      • UPS Input Connection Type: 5-15P
      • Input Circuit Breakers: 15A
      • UPS Input Cord Length (ft.): 10
      • Recommended Electrical Service: 15A 120V
      • Input Phase: Single-Phase

      • Battery:
      • Full Load Runtime (min.): 4.5 min. (1350w)
      • Half Load Runtime (min.): 13 min. (675w)
      • DC System Voltage (VDC): 36
      • Battery Recharge Rate (Included Batteries): Less than 4.5 hours from 10% to 90% (typical, full load discharge)
      • Internal UPS Replacement Battery Cartridge: RBC93-2U
      • Battery Access: Front panel battery access door
      • Battery Replacement Description: Hot-swappable, user replaceable batteries
      • Expandable Runtime: No

        Voltage Regulation
      • Voltage Regulation Description: Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 147
      • Overvoltage Correction: Input voltages between 128 and 147 are reduced by 12%
      • Undervoltage Correction: Input voltages between 83 and 107 are boosted by 14%

        Physical:
      • Cooling Method: Fan
      • Included Mounting Accessory Description: Included 4POSTRAILKIT mounting bracket enables installation in 4 post racks from 20.5 to 36 inches (521 to 914mm)
      • Installation Form Factors Supported with Included Accessories: 4 post 19 inch rackmount
      • Installation Form Factors Supported with Optional Accessories: 2 post rackmount ( 2POSTRMKITWM ); 2-4 post front rail rackmount ( UPSHDEARKIT ); 4 post rackmount short-depth ( 4POSTRAILKITWM ); Tower ( 2-9USTAND ); Wallmount ( 2POSTRMKITWM )
      • Minimum Required Rack Depth (inches): 16.5
      • Primary Form Factor: Rackmount
      • Primary UPS Depth (mm): 342
      • Primary UPS Height (mm): 88
      • Primary UPS Width (mm): 439
      • Rack Height: 2U
      • Shipping Dimensions (hwd / in.): 8.70 x 20.00 x 23.50
      • Shipping Weight (lbs.): 58.50
      • UPS Housing Material: Steel
      • UPS Power Module Dimensions (hwd, in.): 3.45 x 17.3 x 13.45
      • UPS Power Module Weight (kg): 21.09
      • UPS Power Module Weight (lbs.): 46.5

    • GTIN:

      0037332119209
