Sony PXW-FX9 6K 20.5MP Camera with Fast Hybrid AF / Dual Base ISO and S-Cinetone

ITEM #: SNY-PXW-FX9 MFG #: PXW-FX9

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

Our Price:

$11,299.99

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
  • Shipment of this item is subject to a separate oversized-package carrier surcharge.
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


PXW-FX9 - Overview

Discover the FX9, Sony's full-frame 6K sensor camera with Fast Hybrid AF, Dual Base ISO and S-Cinetone™ color science.

Full-Frame Creativity
Realize beautiful 4K imagery with the creative freedom made possible by oversampling a huge high resolution full-frame sensor. Capture every detail from the scene with shallow depth of field and stunning bokeh for a truly cinematic look. 15+ stops of dynamic range and Dual Base ISO enable you to capture every nuance, from subtle shadow detail to specular highlights, with an immaculate color palette.

Capturing The Impossible
Make sure your story's always clear with enhanced Fast Hybrid AF that tracks your subject with unprecedented speed, smoothness, and precision. Its impact is transformative for premium documentary, commercial, and event applications. Your ability to precisely capture your subject's expression is further enhanced with Sony's unique Eye AF* and Real-time Tracking.**

*Ver2.0 is required.
**Ver3.0 is required.

Shoot in Comfort, Expand Your Horizons
The FX9 revolutionizes full-frame cinematography with peerless ergonomics and advanced technology for on-the-go shooting. The world's first full-frame electronic variable ND filter* transforms possibilities for shooting in variable lighting conditions. Built-in Wi-Fi and 12G-SDI support advanced workflows while the optional XDCA-FX9 extension unit further expands the operational possibilities of the PXW-FX9. Ver.2.0 firmware adds HLG and User 3D LUTs while Ver.3.0 enhances support for multi-cam applications with S700 Protocol over Ethernet and anamorphic lens support with de-squeeze x2.0 and x1.3 on viewfinder.

6K Full-Frame "Exmor R" sensor for stunning picture quality
The back-illuminated full-frame 6K CMOS sensor uses Sony's Exmor R technology for improved sensitivity and reduced noise. When recording at DCI 4K* Ultra HD resolutions, the ability to oversample and capture at 6K, combined with powerful image processing, ensures that subtle details and textures beyond those that can be captured by a conventional 4K sensor are retained while at the same time noise is reduced.

Compared to a 4K Super 35mm sensor, the FX9's 6K sensor has over twice the surface area, providing a wider angle of view, making it easier to gain a shallower depth of field. You can also shoot with Super 35mm lenses without compromise, capturing at 4K in super 35 mm with all the benefits of this advanced imaging sensor.

*DCI 4K (4096 x 2160 at 17:9 recording) requires Ver.2.0 or higher firmware.

  • Features:

    • Phenomenal 15+ stops dynamic range for limitless expression
    • Dual Base ISO for stunning images in any light
    • Cinematic color science with S-Cinetone
    • Accelerate your workflow with User 3D Luts and HLG
    • HDR/SDR dual production support
    • Selectable frame rates for full-frame, Super 35 and Super 16
    • 16-bit RAW capability
    • Capture the action with enhanced Fast Hybrid AF
    • Eye AF and Real-time Tracking
    • Customizable AF settings
    • Autofocus with Sony E-mount lenses
    • The world's first electronic variable ND filter for full-frame sensors
    • Quick menu control with touch operation

  • Specifications:

    • General
    • Weight: Approx 4.41 lb (body only). Approx. 10.58 lb (with accessories)
    • Dimensions (W x H x D): 5.75 x 5.61 x 9.02 in
    • Power Requirements: DC 19.5V
    • Power Consumption: Approx. 35.2 W
    • Operating Temperature: 32°F - 104°F
    • Storage Temperature: -4°F - +140°F
    • Battery Operating Time: Approx. 54 min. with BP-U35 battery. Approx. 108 min. with BP-U70 battery.
    • Lens Mount: E-mount

      Camera Section
    • Imaging Device (Type): 1.38 in full-frame, single-chip CMOS image sensor
    • Imaging Device (Pixel Count): 20.5 M pixels (total)
    • Built-in Optical Filters: Clear, linear variable ND (1/4ND to 1/128ND)
    • ISO Sensitivity: ISO 800/4000 (Cine EI mode, D55 light source)
    • S/N Ratio: 57 dB (Y) (typical)
    • Shutter Speed: 64F to 1/8000 sec
    • Slow and Quick Motion Function:
      - FF 6K mode: XAVC-I/L 4096x2160. 1 to 30 frames (29.97/25/24/23.98) / 3840x2160, 1920x1080. 1 to 30 frames (29.97/25/23.98)
      - FFc 5K, S35 4K mode: XAVC-I/L 4096x2160. 1 to 60 frames (59.94p, 50p, 29.97/25/24/23.98) 3840x2160, 1920x1080. 1 to 60 frames (59.94p, 50p, 29.97/25/23.98)
      - FF 2K, S16 2K mode: XAVC-I 1920x1080. 1 to 60, 100, 120, 150, 180 frames (59.94p, 29.97/23.98). 1 to 60, 100, 120, 150 frames (50p, 25)
      - FF 2K, S16 2K mode: XAVC-L 1920x1080 1 to 60, 100, 120 frames (59.94p, 50p, 29.97/25/23.98) / S35 2K mode: XAVC-I/L 1920 x 1080. 1 to 60, 100, 120 frames (59.94p, 50p, 29.97/25/23.98)
    • White Balance: Preset, Memory A, Memory B (2000K-15000K)/ATW
    • Gain: -3 to 27 dB (every 1 dB), AGC
    • Gamma Curve: SDR mode: S-Cinetone, STD1, STD2, STD3, STD4, STD5, STD6, HG1, HG2, HG3, HG4, HG7, HG8, S-Log3 / HDR mode: HLG (Natural/Live)
    • Latitude: 15+ stop

      Input/Output
    • Genlock Input/REF Output: BNC, Genlock IN/REF OUT Switchable
    • TC Input/TC Output: BNC, TC IN/OUT Switchable
    • Audio Input: XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable / Mic reference: -30 to -80 dBu
    • SDI Output: SDI OUT1: BNC, 12G-SDI, 3G-SDI (Level A/B), HD-SDI / SDI OUT2: BNC, 3G-SDI (Level A/B), HD-SDI
    • USB: USB device, micro-B (x1)
    • Headphone Output: Stereo mini jack (x1) -16 dBu 16 Ohm
    • Speaker Output: Monaural
    • DC Input: DC jack
    • Remote: Stereo mini-minijack
    • HDMI Output: Type A (x1)

      Monitoring
    • LCD: 3.46 in (3.5 type) approx. 2.76 M dots

      Built-in Microphone
    • Built-in Microphone: Omni-directional monaural electret condenser microphone

      Media
    • Type: XQD card slot (x2). SD/MS card slot (x1) for saving configuration data. SD card slot also can be used for proxy video recording

      Wi-Fi/NFC
    • Supported Format: IEEE 802.11 a/b/g/n/ac
    • Frequency Band: 2.4 GHz bandwidth
    • Security: WEP/WPA-PSK/WPA2-PSK
    • NFC: NFC Forum Type 3 Tag compliant

  • Item Includes:

    • 1x Body Cap
    • 1x Viewfinder
    • 1x Eyepiece
    • 1x Grip Remote Control
    • 1x IS1293 Power Cord
    • 1x AC Adapter
    • 1x BC-U1A Battery Charger
    • 1x BP-U35 Battery Pack
    • 2x Power Cord
    • 1x USB Cable
    • 2x Operating Guide
