TRENDnet TI-S24048 DIN Rail 48V 240W Power Supply for TI-PG50 v.1.0

TND-TI-S24048 - Overview

• Features:

  • Provides up to 240 Watts (48 V, 5 A) of power for PoE devices such as switches, network cameras, and access points
  • This power supply undergoes a 100 % full load burn-in test
  • Rated for an operating temperature range of -13°F to 158°F (-25°C to 70°C)
  • The built-in active Power Factor Controller (PFC, PF>0.93) helps eliminate unusable reactive power
  • Cooling by free air convection
  • Certified for UL 508 and TUV EN60950-1
  • Overload/short circuit/over voltage/over temperature protection
  • Metal enclosure with integrated DIN-rail mount
  • Compliance to EN55011, EN55022 (CISPR22), EN61204-3 Class B, EN61000-3-2/3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN55024, EN61000-6-2, EN61204-3, heavy industry level, criteria A, SEMI F47, and GL approved
  • Rated for vibration (IEC 60068-2-6)
  • LED indicator confirms power to the unit


• Specifications:

  Interface
  • Input: 100v - 240V AC, 50/60Hz, 1.8A 125V - 370V DC
  • Output: 240 Watts, 48V, 5A
  • DIN-Rail: TS-35/7.5 or 15

    Housing
  • Housing: Metal Case
  • DIN-rail Mount: Yes
  • LED Power Indicator: Yes

    Physical
  • Operating Temperature: -13°F - 158°F (-25°C - 70°C)
  • MTBF: 1,693,000 hours
  • Dimensions: 2.4" x 4.9" x 4.5" (63mm x 125mm x 114mm)
  • Weight: 2.3lbs (1.03kg)

    Certifications
  • CE
  • UL 508CB 60950-1
  • TUV EN60950-1


• Item Includes:

  • TRENDnet TI-S24048 48V 240W Din Rail Power Supply


• Warranty:

  • 1 Year Limited Warranty
