TRENDnet TPE-S44 8-port (4 10/100 4 PoE) PoE Switch (Version v4.0R)

TPE-S44 - Overview

• Features:

  • 4 x 10/100Mbps PoE ports
  • 4 x 10/100Mbps ports
  • 30W PoE power budget
  • 1.6Gbps switching capacity
  • Sturdy metal switch
  • Plug and Play installation
  • Lifetime Warranty*


• Specifications:

  • Standards
  • IEEE 802.1p QoS
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3af (15.4 Watts / port)
  • IEEE 802.3az
  • IEEE 802.3x

    Device Interface
  • 4 x 10/100Mbps PoE ports (port 1~4)
  • 4 x 10/100Mbps Fast Ethernet ports
  • LED indicators

    Data Transfer Rate
  • Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
  • Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)

    Performance
  • Data RAM Buffer: 96KB
  • Switch Fabric: 1.6Gbps
  • MAC Address Table: 2 K entries
  • Forwarding rate: 1.19Mpps (64-byte packet size)

    Special Features
  • GREENnet energy saving technology

    Power
  • Input: 110-240 V AC, 50 / 60 Hz, 0.75 A
  • Output: 48 V DC, 0.8 A
  • Consumption: 2.1 Watts (Max. without PD)

    PoE
  • PoE budget: 30 Watts
  • Pin 1, 2 for power+ and pin 3, 6 for power- (mode A)

    Operating Temperature
  • 0 - 45 °C (32 - 113 °F)

    Operating Humidity
  • Max. 90% non-condensing

    Dimensions
  • 150 x 96 x 28mm (5.9 x 3.8 x 1.1 in.)

    Weight
  • 370g (12.9 oz.)

    Certifications
  • CE
  • FCC


• Item Includes:

  • TPE-S44
  • Quick Installation Guide
  • Power adapter (48 V DC, 0.8 A)


• Warranty:

  • Lifetime Warranty*


• GTIN:

  0710931505061
