Tripp Lite BP72V18-2US 72VDC External Battery Pack Select AVR Online UPS Rack Tower 2U

BP72V18-2US - Overview

• Features:

  • Offers extended-run UPS operation when used in conjunction with compatible 72V DC Tripp Lite UPS systems
  • Includes heavy gauge cabling with high current DC connectors for simple installation
  • Daisychain connector enables the connection of additional compatible 72V external battery packs to the host UPS
  • Included mounting brackets support rackmount installation in 4 post racks using only 2 rack spaces (2U)
  • UPDHDEARKIT option supports 2 point front-rail rackmount installation without rear supports
  • 2POSTRMKITWM option supports balanced 2 point center-mounting in 2 post equipment racks
  • 2POSTRMKITWM option also enables wallmount installation
  • 2-9USTAND option enables upright tower placement


• Specifications:

  • Overview
  • UPC Code:037332178008

    Input
  • Input Phase:Single-Phase

    Battery
  • DC System Voltage (VDC):72
  • UPS Connection:Attached cable with black 3-point DC connector
  • Typical Battery Lifespan:4-6 years typical (North America)

    Physical
  • Installation Form Factors Supported with Included Accessories:4 post 19 inch rackmount
  • Installation Form Factors Supported with Optional Accessories:2 post rackmount (2POSTRMKITWM); Wallmount (2POSTRMKITWM); Tower (2-9USTAND); 2-4 post front rail rackmount (UPSHDEARKIT)
  • Minimum Required Rack Depth (inches):31.8
  • Shipping Dimensions (hwd / in.):9.00 x 28.00 x 26.00
  • Shipping Weight (lbs.):126.00
  • Unit Dimensions (hwd / in.):3.4 x 17.3 x 20.8
  • Unit Weight (lbs.):88.2
  • Material of Construction:Steel
  • External Battery Pack Form Factor:Rack/Tower


• Item Includes:

  • BP72V18-2US external battery pack with attached DC cabling
  • 4 post compatible mounting hardware
  • Owner's manual


• Warranty:

  • 2-year limited warranty


• GTIN:

  0037332178008
