ADDERLink ALIF2020R-US INFINITY Dual Head Digital USB2.0 IP KVM A/V Extender - Receiver

ITEM #: ADR-ALIF2020R-US MFG #: ALIF2020R-US

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$1,570.00

Our Price:

$1,491.50

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


ALIF2020R-US - Overview

The ADDERLink ALIF2002R INFINITY Dual Receiver is a high performance KVM (Keyboard, Video and Mouse) extender that forms part of the ADDERLink INFINITY Range. This enables you to locate your critical computing hardware in a secure and temperature controlled environment away from the user work station, whilst maintaining a pixel perfect desktop experience.

Part of the ADDERLink™ INFINITY range, the ADDERLink™ INFINITY Dual 2020 is a high performance KVM solution that enables you to isolate critical computing hardware in a secure and temperature controlled environment. Configurable as a single link or dual head, this extender provides an at-the-PC experience across up to 6.21 miles/10km assuring the digital video you receive is the same as the digital video leaving the remote computer, with no loss of compression and minimal lag. The Dual 2020 comes with a choice of single mode or multimode fiber modules to suit your specific application (sfp sold separately). This KVM extender can be used as a point to point extender or can be integrated into a wider matrix system when combined with the ADDERLink INFINITY Manager (AIM).

Please Note: The ALIF2020R receiver requires at least one ALIF2020T transmitter to operate (sold separately).

  • Features:

    • Perfect digital video: uncompressed video extension and pixel perfect digital video up to 24 bits per color at a maximum of 1920x1200 over 60Hz with real time control
    • Digital Stereo Audio: digitally delivered crystal clear audio across the network
    • Distribution: DVI, USB, audio and bidirectional RS232 across up to 6.2 miles/10km
    • Power redundancy: the units can detect whether the network is in operation and will utilize the second network port is failure detected
    • EDID management: Extended Display Identification Data (EDID) enables the remote system to exactly mirror the date coming from the source monitor
    • Plug and Play: the ADDERLink INFINITY range is delivered in a zero config state so they work as soon as they are connected, without the need for drivers or software
    • Robust yet lightweight: small form factor, rack mountable device
    • USB True Emulation: USB 2.0 enables connection to any USB human interface device from mice and keyboards through to graphics tablets, jog shuttles, joysticks and 3D explorers

  • Specifications:

    • Hardware compatibility: All computers with DVI-D, USB, audio, RS232 - requirement dependent.

    • DVI-D - Digital Visual Interface (digital only): The system supports two Single Link DVI-D resolutions to a maximum of 1920 x 1200 @ 60Hz.

    • USB 2.0 with class control: Supports USB2.0 devices (low, full and high speed). Security feature allows the blocking of non HID devices. Isochronous devices are not supported (e.g. USB audio or video devices).

    • Digital stereo audio: The system transfers analog stereo audio (Line In/Line Out) via digital signaling between any transmitter/receiver pair. Additionally, the audio output of any transmitter can be multicast to many receivers.

    • RS232: RS232 can be passed between the units to a maximum baud rate of 115,200. RS232 is a point to point connection technology and cannot be multicast.

    • Software compatibility: All known operating systems

    • Peripheral connections receiver (RX):
    • 2 x DVI-D
    • Audio 3.5mm in, audio 3.5mm out
    • 4 x USB type A
    • RS232 9-pin D-type
    • 1 x 8p8c and 1 x SFP for ADDERLink INFINITY network connections.

    • Physical design:
    • 1U compact case, robust metal construction.
    • 198mm/7.92" (w), 44mm/1.76" (h), 150mm/6.0" (d)
    • Weight - 1.1kg/2.7lbs.

    • Power:
    • 2.5mm DC jack (power adapter included),
    • 100-240VAC 50/60Hz, 0.8A, input to power adapter.
    • 5VDC 20W output from power adapter.

    • Operating temperature: 0 to 40°C / 32 to 104°F.

    • Approvals: CE, FCC

  • Item Includes:

    • 1x ALIF2020R unit
    • 1x Power adapter and US power cord

  • Warranty:

    • 2 Year Limited

  • GTIN:

    0818252035875
