AJA Ki Pro Go Multi-Channel H.264 3G-SDI USB 3.0 Recorder and Player

ITEM #: AJA-KI-PRO-GO MFG #: KI-PRO-GO

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the AJA-KI-PRO-GO

KI-PRO-GO - Overview

The AJA Ki Pro Go is a portable multi-channel H.264 recorder offering up to 4-channels of simultaneous HD and SD recording to off the shelf USB drives with redundant recording capabilities, and now with new v3.0 firmware, recording to network storage.

4x 3G-SDI and 4x HDMI digital video inputs with flexible channel assignments provides connections to the latest video sources, including cameras and DSLRs. Incoming video sources do not have to be genlocked due to Ki Pro GO's input frame syncs. Ki Pro GO also features AJA's high quality de-interlacers on each input so progressive recordings can be made from interlaced inputs. High quality 2-channel embedded audio or balanced XLR analog audio can be assigned to any recording channel. Multi-Channel Matrix Monitoring enables multiple video channels to be viewed on any single HDMI or SDI display, and Enhanced Super Out offers timecode, media status and audio meter overlays over the SDI and HDMI monitor outputs.

Designed to be either portable or rackmountable with half rack wide, 2RU high dimensions, Ki Pro GO is well suited for use in any environment.

  • Features:

    • Multi-channel H.264 recording
    • 5x USB recording media ports, compatible with off-the-shelf USB 3.2 Gen 1 media
    • In system exFAT drive formatting
    • Redundant recording to user selectable usb ports
    • Recording to network (SMB) storage (new in v3.0)
    • Redundant recording to user selectable destinations - USB or SMB (new in v3.0)
    • Genlock free inputs
    • 4x 3G-SDI inputs
    • 4x 3G-SDI outputs
    • 1x 3G-SDI monitoring output
    • 4x HDMI inputs
    • 1x HDMI monitoring output
    • HDMI and SDI multi-channel matrix monitoring
    • HDMI and SDI Enhanced Super Out for monitoring: timecode, media status and audio levels
    • Single-channel H.264 playback
    • Selectable VBR recording settings with 5 options
    • Timecode Input Support: Time of Day/Timecode Value/SDI RP-188/LTC
    • Available using 1-channel of Analog Audio In
    • Balanced XLR analog audio inputs, mic/line/48v switchable
    • 2-channel embedded audio per video input
    • Easy-to-use web UI, compatible with standard web browsers
    • Network web UI based file downloads
    • Front panel button controls with integrated HD resolution screen
    • Stand-alone operation

  • Specifications:

    • Video Formats
    • (HD) 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
    • (HD) 1080i 50, 59.94, 60*
    • (HD) 1080PsF 23.98, 24, 25, 29.97, 30*,**
    • (HD) 720p 50, 59.94, 60
    • (SD) 525i 59.94*
    • (SD) 625i 50*
    • * Recording will be converted to progressive
    • ** PsF input support only
    • Note: Multi-channel recording requires the same frame rate and resolution for all input sources.

      Video/Audio Codec Support
    • Supports H.264/MPEG-4
    • 1 Mbps to 25 Mbps recorded output (TBD)
    • 4x audio compression codecs
    • 2-Channel audio support for each
    • up to 320 kbps (TBD)
    • MPEG-4 AAC-LC

      Removable Storage
    • 5x USB 3.0 Slots
    • All slots are compatible with the following standards: USB 2.0, USB 3.0, USB 3.1 Gen 1, USB 3.1 Gen 2
    • 5V 1A max current per slot

      Video Input
    • 4x 3G-SDI BNC, SMPTE-259/292/296/424/425, 4:2:2 10-bit
    • 4x HDMI standard Type A connector
    • HDMI v1.4a: 4:4:4 RGB 8, 10-bit (deep color); 4:2:2 YCbCr 8/10/12-bit; 4:2:0 YCbCr 8-bit

      Video Output
    • 5x 3G-SDI BNC, SMPTE-259/292/296/424/425, 4:2:2 10-bit
    • 1x HDMI standard Type A connector
    • HDMI v1.4a: 4:4:4 RGB 8, 10-bit (deep color), 4:2:2 YCbCr 8/10/12-bit, 4:2:0 YCbCr 8-bit

      Audio Input
    • 4x SDI Audio: 2-Channel, 24-bit embedded audio
    • 48 kHz sample rate, synchronous; Sample rate converted to 48 kHz internally
    • 4x HDMI Audio: 2-Channel, 24-bit HDMI embedded audio; 32 kHz, 44.1 kHz, 48 kHz sample rates, synchronous; Sample rate converted to 48 kHz internally
    • 2x XLR input: Line/Mic/+48V Phantom Power Mic Levels supported (selectable by rear switch)

      Audio Output
    • 5x SDI embedded: 2-Channel, 24-bit embedded audio; 48 kHz sample rate, synchronous
    • 1x HDMI embedded: 2-Channel, 24-bit embedded audio; 48 kHz sample rate, synchronous
    • Stereo unbalanced headphone jack (1x 3.5mm jack) with volume control
    • 2-Channel unbalanced 2x RCA connectors

      Physical
    • Size (W x D x H): 8.64" x 10.59" x 3.31" (219.46 x 268.60 x 84.08 mm)
    • Weight: 5.1 lbs (2.3 kg)
    • Power: Dual, redundant, 7.5A max, 40W-55W typical-90W Max; 100-240 VAC 50/60 Hz (adapter); 12-18Vdc 4-pin XLR (chassis)
    • Safe Operating Temperature: 0 to 40 °C (32 to 104° F)
    • Safe Storage Temperature (Power OFF): -40 to 60° C (-40 to 140° F)
    • Operating Relative Humidity: 10-90% noncondensing
    • Operating Altitude: <3,000 meters (<10,000 feet)

  • Warranty:

    • Three Year

  • GTIN:

    0812321031935
