The Alfratron SCK51TS-D is a 5 x 1 seamless presentation switcher with an HDBaseT receiver that supports video resolutions up to 4K@60Hz 4:4:4, 8 bit deep color and is HDCP 2. 2 compliant. It features a multi view function for allowing multiple sources to be displayed on single screen. This switcher supports HDMI and HDBaseT mirrored outputs and using HDBaseT extends uncompressed 4K up to 132ft/40m or 1080P up to 230ft/ 70m via a single Cat6a cable.
This switcher has five video inputs: two USB C and three HDMI inputs. Each USB C input supports LT DP mode with up to 4K@60Hz 4:4:4 with 8 bit deep color, USB 2 .0 data and 60W power charging to USB C source device. It also features ethernet over USB C functionality to allow USB C source devices to access the internet seamlessly. Local USB KVM switching and extending USB 2.0 over HDBT can be allowed to connect external USB 2.0 devices or cameras for video conference.
This switcher has built in Dante audio input and output interface, and it can be seamlessly connected to any existing audio processing system with Dante enabled. This switcher can be controlled via front panel buttons, remote control, API commands using RS 232 or the TCP/IP A Web server with a GUI built in that features A/V control, automatic display control and input EDID management. The product is ideal for software based video teleconference rooms.
