Amphenol 034-1121-12G Straight Crimp Plug 12G HD-BNC Connector for Belden 4694R Cable - 75 Ohm

ITEM #: AMPH-034-112112G MFG #: 034-1121-12G

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Amphenol
Free Shipping with $49 Minimum Order

List Price:

$17.00

Our Price:

$15.48

Quantity Pricing

Add to Wish ListLeasing Options
Availability: In Stock
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

034-1121-12G - Overview

The 034-1121-12G is a 12G Optimized, 75 Ohm RF Connector, HD-BNC Straight Crimp Plug for the Belden 4694R Cable.

Please note! This is an HDBNC connector also known as a "micro BNC" connector. They are much smaller and narrower than standard BNC connectors.

  • Specifications:

    • Orientation: Straight
    • Termination Style: Cable - Crimp
    • Impedance (Ohms): 75
    • Body Finish: Nickel
    • Body Material: Brass
    • Contact Finish: Gold
    • Contact Material: Phosphor Bronze
    • Contact Termination Style: Crimp
    • Insulator Material: PTFE
    • Cable Group: Special
    • Cable Type: Belden 4694R
    • Crimp Tool: CTL-14
    • Coupling Mechanism: Bayonet
    • Max Frequency (GHz): 18
    • Polarity: Standard
    • Min. Temp. (Celsius): -30
    • Max. Temp. (Celsius): 85
    • Mating Cycles: 500
