ATEN KH1508Ai 8-Port 1 User(1 IP or 1 Local) Cat5 IP KVM Switch - TAA Compliant

KH1508AI - Overview

• Features:

  • Dedicated USB port directly connects to a laptop for easy console operation
  • High port density - RJ-45 connectors for up to 16 ports in a 1U housing
  • One bus for remote KVM over IP access
  • Supports PS/2, USB, Sun Legacy (13W3) and serial (RS-232) connectivity
  • Local console provides PS/2 and USB keyboard and mouse support
  • Supports multiplatform server environments: Windows, Mac, Sun, Linux and serial devices
  • High video resolution - up to 1600 x 1200 @ 60Hz at up to 130 ft.(40m) and 1280 x 1024 @ 75Hz at up to 165 ft.(50m), with the new ATEN KVM Cable Adapter KA7000 series.
  • Daisy chain up to 31 additional units - control up to 256 (KH1508Ai) or 512 (KH1516Ai) computers from a single console.
  • Up to 64 user accounts - up to 32 users simultaneously share the control
  • End session feature - administrators can terminate running sessions
  • Event logging and Windows-based Log Server support
  • Local Log Event
  • Firmware upgradeable
  • Adapter ID - stores port information allowing administrators to relocate the servers to different ports, without having to reconfigure the adapters and switch
  • Port Share Mode allows multiple users to gain access to a server simultaneously
  • Integration with ALTUSEN CC2000 Management software
  • Local Console, Browser, and AP GUIs offer a unified multi-language interface to minimize user training time and increase productivity
  • Multiplatform client support (Windows, Mac OS X, Linux, Sun)
  • Multi-browser support (IE, Mozilla, Firefox, Safari, Opera, Netscape)
  • Browser-based User interface in pure Web technology allows administrators to perform administrative tasks with no need for Java to be pre-installed
  • User can launch multiple Virtual Remote Desktops to control multiple connected servers from the same login session
  • Full-screen or sizable and scalable Virtual Remote Desktop
  • Panel Array Mode
  • Device ID and attributes are stored in the adapter cables allowing you to hot-swap port connections without having to reconfigure attributes.
  • Local keyboard broadcast - keyboard input can be duplicated on all the attached servers.
  • Remote authentication support: RADIUS, LDAP, LDAPS, and MS Active Directory
  • Advanced security features include password protection and advanced encryption technologies - 1024 bit RSA; 56 bit DES; 256 bit AES; and 128 bit SSL
  • Flexible encryption design allows users to choose any combination of 56- bit DES, 168-bit 3DES 256-bit AES, 128-bit RC4, or Random for independent KB/Mouse, video, and virtual media data encryption
  • Support for IP/MAC Filter
  • Configurable user and group permissions for server access and control
  • Video quality and video tolerance can be adjusted to optimize data transfer speed; monochrome color depth setting, threshold and noise settings for compression of the data bandwidth in low bandwidth situations
  • Full screen or scalable video display
  • Message Board for communication among remote users
  • Mouse DynaSync - automatically synchronizes the local and remote mouse movements
  • On-screen keyboard with multi-language support


• Specifications:

  • Computer Connections
  • Direct 16
  • Daisy Chain or Cascading 512
  • Port Selection OSD / Hotkey / Pushbutton
  • Connectors
  • Keyboard 1 x 6-pin Mini-DIN Female / 1 x USB Type A Female
  • Mouse 1 x 6-pin Mini-DIN Female / 1 x USB Type A Female
  • Video Output 1 x HDB-15 Female
  • AC Power Inlets 1 x 3-prong AC socket
  • LAN 1 x RJ-45 Female
  • Power 1 x 3-prong AC socket
  • PON 1 x RJ-45 Female
  • USB 1 x USB Mini Type B Female [VNC console]
  • KVM Side Connections
  • Keyboard, Video, Mouse 16 x RJ-45 Female
  • Daisy Chain 1 x DB-25 Male
  • Switches
  • Power 1 x Rocker
  • Port Selection 16 x Pushbutton
  • Reset 1 x Semi-recessed Pushbutton
  • LEDs
  • Power On 1 (Blue)
  • On Line 16 (Green)
  • Selected 16 (Orange)
  • Station ID 1 x 2-digit 7-segment (Orange)


• GTIN:

  0672792400377
