ATEN VE901 DisplayPort Cat6 HDBaseT-Lite Extender Transmitter & Receiver Kit - 4K40m 1080p70m

Name: ATEN VE901 DisplayPort Cat6 HDBaseT-Lite Extender Transmitter & Receiver Kit - 4K40m 1080p70m
Brand: ATEN
SKU: ATEN-VE901
Price: 419.90 USD
Availability: PreSale

ITEM #: ATEN-VE901 MFG #: 9B0998

ATEN

List Price:

$442.00

Our Price:

$419.90

Add to Wish List Leasing Options

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

9B0998 - Overview

The ATEN VE901 DisplayPort HDBaseT-Lite Extender is able to extend a DisplayPort display up to 70 m using a Cat 6/6a/ATEN 2L-2910 Cat 6 cable. This combination of ATEN and HDBaseT™ technology supports sharing 4K media up to 40 m away, offering a simple, adaptable, and cost-effective solution for any professional A/V installation.

The VE901 DisplayPort HDBaseT-Lite Extender is the perfect solution for professional A/V installations that require video signal interference protection, such as in medical and military installations. With its lightweight and easy-to-mount design, and a slip-resistant DC Jack lock mechanism, the VE901 can be installed in a multitude of locations while ensuring peace of mind with its reliability.

Note: DisplayPort v1.1 supports up to 4Kx2K @ 30Hz.

Features:
- HDBaseT Connectivity - extends a DisplayPort connection up to 70 meters via a single Cat 6a cable or ATEN 2L-2910 Cat 6 cable
- DisplayPort v1.1*; HDCP 1.4 compliant
- Superior video quality - 4K @ 35 m (Cat 5e/6) / 40 m (Cat 6a/ATEN 2L-2910 Cat 6 cable) and 1920 x 1080 @ 60m (Cat 5e/6) / 70m (Cat 6a/ATEN 2L-2910 Cat 6 cable)
- HDBaseT Anti-Jamming - resists signal interference during video transmission using HDBaseT technology
- Featuring 3.3V / 500mA power output for powering auxiliary devices
- Plug-and-play
- Rack-Mountable
Specifications:
- VE901T Video Input
- Interfaces: 1 x DisplayPort Female (Black)
- Impedance: 100 Ω
- Max. Distance: 1.5 m

  VE901R Video Output
- Interfaces: 1 x DisplayPort Female (Black)
- Impedance: 100 Ω

  Video
- Max. Data Rate: 10.2Gbps (3.4Gbps per lane)
- Max. Pixel Clock: 297 MHz: 297 MHz
- Compliance: DisplayPort (Deep Color, 4K) HDCP Compatible
- Max. Resolutions / Distance: Up to 4K@35m (Cat 5e/6) / 40m (Cat 6a); 1080p@60m (Cat 5e/6) / 70m (Cat 6a) *4K supported: 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)

  Audio
- Input (VE901T): x DisplayPort Female (Black)
- Output (VE901R): 1 x DisplayPort Female (Black)

  Connectors
- Power: 1 x DC Jack (Black) with locking
Item Includes:
- 1x VE901T DisplayPort HDBaseT-Lite Transmitter
- 1x VE901R DisplayPort HDBaseT-Lite Receiver
- 2x Power Adapters
- 1x User Instructions
GTIN:
0672792403804
