Lilliput BM150-12G-ABBP 15.6 Inch 12G-SDI & 4K HDMI Broadcast Director Monitor w/ Gold Mount Plate

BM150-12G-ABBP - Overview

• Features:

  • 4K (3840*2160) Ultra-HD native resolution
  • 15.6" perfect size for both suitcase & rackmount
  • High contrast: 1000:1
  • 330cd/m² brightness
  • 176° Ultra high viewing angle
  • Abundant interfaces: 12G-SDIx2, 3G-SDIx2, HDMI 2.0x1 HDMI1.4x3, Tally input
  • 12G-SDI single link, dual link and 3G-SDI quad link
  • Metal housing
  • Wide voltage: DC12-24V


• Specifications:

  • Display
  • Display Screen: 15.6" IPS
  • Physical Resolution: 3840 x 2160
  • Aspect Ratio: 16:9
  • Brightness: 330cd/m²
  • Contrast: 1000:1
  • Viewing Angle: 176°/176° (H/V)

    Input
  • 12G-SDI: 2
  • 3G-SDI: 2
  • HDMI: 2.0x1 (Support 4K 60Hz); 1.4x3 (Support 4K 30Hz)
  • Tally: 1

    Output
  • 12G-SDI: 2
  • 3G-SDI: 2

    Audio
  • Speaker: 1
  • Earphone Slot: 1

    Power
  • Current: 2.8A(15V)
  • Input Voltage: DC 12-24V (XLR)
  • Battery Plate:Anton Bauer mount
  • Power Consumption: <34W

    Environment
  • Operating Temperature: -4 to 140°F
  • Storage Temperature: -22 to 158°F

    Dimension
  • Dimension (LxWxD): 15.32 x 10.51 x 1.50" / 20.63 x 12.01 x 6.69" (with case)
  • Weight: 7.50 lbs. / 26.46 lbs. (with case)
