Blackmagic Design BMD-SWATEMTVSTU/PRO4K ATEM Television Studio Pro 4K - B-Stock (Refurbished)

ITEM #: BMDATEMSTUDPR4KB MFG #: BMDATEMSTUDPR4KB

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the BMDATEMSTUDPR4KB

BMDATEMSTUDPR4KB - Overview

The ATEM Television Studio Pro 4K by BlackMagic Design features 8 independent 12G-SDI inputs, for working in all popular HD and Ultra HD formats up to 2160p60. Each input features re-sync as well as a full low latency standards converter, which means the input is automatically adapted to the switchers format. You can even have 8 inputs, all running different video formats! The upgraded Fairlight audio mixer features dynamics, 6 band parametric EQ, dual mono channel split and stereo simulator with audio delay on the analog inputs. ATEM Television Studio Pro 4K also features the ATEM Advanced Chroma Key, Ultra HD multi-view and motion clips in the media pool.

Note: This is a B-Stock item. It has been refurbished by the vendor.

  • Features:

    • Note: This is a B-Stock item. It has been refurbished by the vendor.


  • Specifications:

    • Connections
    • Total Video Inputs: 8
    • Total Outputs: 12
    • Total Aux Outputs: 1
    • SDI Rates: 1.5G, 3G, 6G,12G
    • Total Audio Inputs: 2 x XLR. 1 x Microphone
    • Total Audio Outputs: 1 x Headphone
    • SDI Video Inputs: 8 x 10-bit HD/UHD switchable. 2 channel embedded audio
    • HDMI Video Inputs: None
    • Reference Inputs: Tri-Sync or Black Burst
    • Video Input Re-Sync: On all 8 inputs
    • Frame rate and format convertors: On all 8 inputs
    • SDI Program Outputs: 9 x 10-bit HD/UHD switchable
    • SDI Audio Outputs: 2 Ch embedded into SDI output
    • Multi View Monitoring: 1
    • Multi View Video: 1 x SDI and 1 x HDMI

      Standards
    • SD Video Standards: None
    • HD Video Standards: 720p50, 720p59.94, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p50, 1080p59.94, 1080i50, 1080i59.94
    • Ultra HD Video Standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p50, 2160p59.94
    • SDI Compliance: 292M and 424M, 2081, 2082
    • Video Sampling: 4:2:2 10-bit
    • Color Precision: 4:2:2 10-bit
    • Color Space: 4:2:2 YUV
    • Input Resolutions for Computers: 720p50, 720p59.94; 1080p23.98, 1080p24, 1080p25, 1080p29.97,1080p30, 1080p50, 1080p59.94, 1080p60; 1080i50, 1080i59.94, 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
    • Colorspace Conversion: None
    • Processing Delay: 6 Lines

      General
    • Upstream Keyers: 1 with Chroma/Linear/Luma key
    • Downstream Keyers: 2
    • Chroma Keyers: 1
    • Linear/Luma Keyers: 3
    • Talkback Support: Built in, uses aviation headset
    • Mix Minus Support: Yes, on 8 camera PGM outputs
    • Transition Keyer (Stinger/DVE): Stinger and DVE
    • Total Number of Layers: 5
    • Pattern Generators: 2
    • Color Generators: 2
    • DVE with 3D Borders & Drop Shadow: 1
    • Interface: Minimum monitor resolution of 1366 x 768
    • Number of Windows: 1 x 10
    • Routable Windows: 8 routable and 2 fixed for Program and Preview
    • Tally: Red for program and green for preview indication
    • Tally Output: Embedded via SDI. Added via ethernet connection to Blackmagic Design GPI and Tally Interface product (Not included)
    • Windows Source Labels: Yes

      Physical
    • Power Supply: 1 x Internal 110 - 240V AC. 4 pin 12V DC
    • Power Usage: 70W
    • Operating Temperature: 5° to 40°C
    • Storage Temperature: -20° to 60°C
    • Relative Humidity: 0% to 90% non-condensing


  • Item Includes:

    • ATEM Television Studio Pro 4K
    • SD card with software and manual


  • Warranty:

    • 1 Year
