Bolin EG40N NDI to 12G-SDI/HDMI 2.0 High Bandwidth NDI/HX3 Decoder - Supports up to 4K60 - PoE+

EG40N - Overview

• Features:

  • Supports up to 4K60 Video Output
  • Video Upscaling up to 4K60
  • HDMI 2.0 + 12G-SDI simultaneous video output
  • NDI High Bandwidth, NDI HX3, and IP Decoder
  • POE+ and 12VDC power input


• Specifications:

  • Codec
  • Decoder (Video Output): HDMI & SDI
  • Video Codec: NDI High Bandwidth (NDI 6 Ready), NDI HX3 supported, AVC-H.264 / HEVC-H.265 selectable
  • Codec Platform: Hardware FPGA FAST HEVC codec
  • Video Resolutions: 3840 x 2160P @60/59.94/50/30/29.97/25/24/23.98 1920 x 1080P @60/59.94/50/30/29.97/25/24/23.98 1920 x 1080i @60/59.94/50 1280 x 720P @60/59.94/50/30/29.97/25
  • Color Space(HDMI): 4K60: RGB 8bit, YUV444 8bit, YUV422 12bit, YUV420 8bit/10bit 4K30 & below: RGB 8bit/10bit, YUV444 8bit/10bit, YUV422 12bit
  • Audio Formats: 3.5mm Jack, analog audio, stereo (unbalanced); Line in/out - audio intercom, Line out - HDMI audio output
  • Video Streaming: 1 stream
  • Latency (Results may vary depending on network configuration and management settings): NDI certified, <100ms
  • Bandwidth (Results may vary depending on network configuration and management settings): A: 4kp60 4:2:2/12bit; 250Mbps B: 1080p60 4:2:2/12bit; 80-110Mbps
  • Ecosystem: NDI 6, NDI HX3

    Video
  • Highest Resolution: Up to 4K (3840x2160)
  • Highest Frame Rate: Up to 60
  • Video Codec: AVC-H.264 / HEVC-H.265
  • Video Format: 3840 x 2160P @60/59.94/50/30/29.97/25/24/23.98 1920 x 1080P @120/60/59.94/50/30/29.97/25/24/23.98 1280 x 720P @60/59.94/50/30/29.97/25
  • Frame Rates (Hz): 23.98, 24, 25, 30, 29.97, 50, 59.94, 60
  • Application Protocols: RTP, RTSP. MP2TS over UDP, TS over RTP, TS over SRT, HTTP, IGMP v1/v2, DHCP, SSH, 802.1X Authentication

    Audio
  • Audio Compression: AAC-LC, MPEG-2
  • Line-in/Line-out: Support audio intercom
  • Bit Depths: AAC-LC, MPEG-2 (sampling rate: 48KHz/44.1KHz, 24bit, 64-256Kbps selectable)
  • Audio S/N Ratio: ≥85dB
  • Audio THD+N: ≤0.05%
  • Audio Noise (RMS): ≤-90dB
  • Embedded Audio over HDMI: Stereo 2-channel, Dante AV-H ( Audio Flow x 4 Flows / 2 Channels per Flow)
  • Embedded Audio over SDI: Stereo 2-channel
  • Line-out: 3.5mm Jack, analog Line-out

    Communication:
  • Ethernet General A: Standard 1Gbps Ethernet
  • Ethernet General B: Auto-switching, auto-negotiating, auto discovery, full/half duplex
  • ETHERNET with POE A: IEEE 802.3at compliant 1000BASE-T Ethernet port
  • ETHERNET with POE B: IEEE 802.3at Type 3 compliant, PoE+ Class 4
  • HDMI OUTPUT (Decoder only): HDMI 2.0 Type A connector, female; HDMI digital video/audio output
  • PTZ Camera IR Receiver: Front and Back, bidirectional

    Physical
  • Weight: 5.62 lbs
  • Dimensions: 12.8 in x 10.9 in x 3.77 in


• Item Includes:

  • 1x EG40 Series Decoder
  • 1x 12V, 4A Locking Power Adaptor with International Plugs
  • 1x IR Remote Controller
  • 1x Base Mount Kit
  • 1x Surface Mount Kit
  • 1x HDMI Cable Support
  • 1x Mounting Screw Set


• Warranty:

  • 2-Year Limited Warranty


• GTIN:

  6973775121994
