Burst Electronics DV-4 Analog to SDI Converter 10-Bit

ITEM #: BURST-DV-4 MFG #: DV-4

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Burst Electronics
Free Shipping with $49 Minimum Order

List Price:

$895.00

Our Price:

$843.53

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.
Report Lower PriceLarge Quantity Quote

DV-4 - Overview

The DV-4 is a true 10-bit Analog to SDI converter. Features include full proc amp control of the incoming analog video, allowing for corrections and adjustments. The DV-4 supports all popular analog formats in NTSC, PAL, and SECAM. The input section has anti-aliasing filters that allow clean conversion of satellite and ENG sources. Internal color bars and Pathological generators add to the functionality of the DV-4.

  • Features:

    • Full 10-bit processing throughout
    • Supports ALL popular baseband analog video formats, including YPbPr (YUV), Betacam, RGB, NTSC, PAL, SECAM, and YC
    • 2D 5-line Adaptive comb filter
    • Automatically senses PAL/NTSC/SECAM inputs
    • Full locally adjustable video processing levels including Contrast, Setup, Hue, Saturation, and Cr/Cb color gain
    • Built-in Full-field Color Bar and Pathological Test patterns
    • Dual SMPTE 259M outputs
    • Internal anti-aliasing filter for satellite and ENG cameras
    • Lock Status LED
    • Crystal PPL yields < 500 ps output jitter
    • Freq Response Flat to 5.5 MHz
    • Diff gain: 1%
    • Diff phase: 0.5 degrees
    • Dimensions: 4.2W x 1.5H x 5.5D (inches)
    • Input power 5 VDC - overvoltage/reverse voltage protected
    • Power Supply included
