Digital Forecast UHD X TS UHD/FHD Signal Converter Measurement and Test Pattern Generator - 12G SDI/HDMI 2.0/12G Optic

ITEM #: DF-UHD-X-TS MFG #: UHD X TS

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
DIGITAL FORECAST
Free Shipping with $49 Minimum Order

List Price:

$5,199.00

Our Price:

$4,980.00

After Savings:

$4,419.15

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Purchase today for 15% and a Free 98Wh Li-Ion V-Mount Battery For a limited time only, get 15% off and a free Gentree V Mount battery with your order. Your free battery will ship with your X_TS order, contact us today! See Details
Report Lower PriceLarge Quantity Quote

UHD X TS - Overview

UHD Up/Down/Cross/Scan Converter
The Digital Forecast UHD X TS is a multi-platform UHD signal converter with measurement and test pattern generator. UHD X TS can be used anywhere UHD video signals are required. This UHD signal converter is very handy tool with powerful functions that enables you to conveniently check a variety of UHD signal statuses through its 7" LCD touch screen.

Please note: SFPs sold separately.

  • Features:

    • UHD Up/Down/Cross/Scan Converter
    • Standard UHD & FHD video signals supported (12G-SDI, HDMI 2.0, 12G Optic)
    • Embedded audio signal monitor with speaker-out
    • EYE monitoring for SDI signals (720p, 1080i, 1080p, 2160p)
    • Test pattern generator (Still, Moving UHD Generator)
    • 12G-SDI signal integrity check (Loss, Resolution, HDCP)
    • Audio level monitoring (up to 8 channels)
    • 7" LCD touchscreen (1024x600)
    • Supports V-Mount battery plates


  • Specifications:

    • Video Standards
      - SMPTE-296M: 720p (60/59.94/50)
      - SMPTE-274M: SMPTE-292M: 1080i (60/59.94/50)
      - SMPTE-424M: 1080p (60/59.94/50) 3G
      - SMPTE-ST2081: 2160p (30/29.97/25) 6G
      - SMPTE-ST2082: 2160p (60/59.94/50) 12G
      - HDMI 2.0
    • Screen: 7" LCD touchscreen (1024x600)
    • EYE Monitoring Signals: 720p, 1080i, 1080p, 2160p
    • Standard UHD & FHD Video Signals: 12G-SDI, HDMI 2.0, 12G Optic
    • Power Level: +12V DC
    • Power Consumption: 40 Watts (max 45 Watts)
    • Operating Temperature: 32°F - 158°F (0°C - 70°C)
    • Humidity: 0% - 95% RH, Non-condensing
    • Weight: 8.8lbs
    • Dimensions: 14.37" x 10.6" x 5.95"


  • Item Includes:

    • 1x Digital Forecast UHD X TS UHD/FHD Signal Converter Measurement and Test Pattern Generator
    • 1x Hardshell Case
    • 1x12V AC/DC Adapter
