SmallHD MON-INDIE-7 7-inch Smart Touchscreen Monitor with Daylight Visibility - 920x1200 / 323 PPI - SDI/HDMI/Micro USB

ITEM #: INDIE-7 MFG #: MON-INDIE-7

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
SmallHD
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

Our Price:

$1,399.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

MON-INDIE-7 - Overview

SmallHD Indie 7 is the vivid, lightweight entry model into SmallHD's professional 7-inch touchscreen monitor series. This hyperresponsive touchscreen monitor is powered by the user-customizable PageOS 4 software, with a host of internal imaging assistance tools such as Focus Assist, Exposure Assist, and more. Indie 7 provides a personalized viewing experience designed to improve your workflow. Backed by 1000nits of brightness for daylight visibility. Housed in a lightweight, rugged, and thin aluminum chassis designed for heavy production use.

Upgrade to Camera Control for RED® DSMC2® & KOMODO™
Transform your touchscreen into the central command hub of your camera. SmallHD's proprietary software enables unfettered access to RED® DSMC2® & KOMODO™ camera functions and project settings such as Start/Stop Record, FPS, Shutter Speed, ISO, Color Temperature/White Balance, Clip Playback, and more. *Individual Camera Control software licenses are sold separately. Shop KOMODO. Shop DSMC2.

PageOS 4 Software Toolset
With the power of PageOS 4 software, utilize all of the dependable SmallHD internal toolset features such as customizable frame guides, Focus Assist, Exposure Assist, high-resolution 3D LUT overlays (via Full SD Card slot), histogram, vectorscope, waveform, and Teradek RT Overlays. Learn more about PagesOS 4

Compatible with Bolt RX Monitor Module
Improve your handheld monitoring workflow with this optional hardware addition to your Indie 7 monitor. Receive cable-free 4K and HDR wireless video from any Bolt 4K series transmitter at a distance of up to 750ft (228m). With 1:1 Pixel Mapping, utilize the added resolution to punch-in and achieve tack-sharp critical focus. Learn more about.

  • Features:

    • Responsive Touchscreen with Daylight Visibility
    • Full HD 7-inch IPS LCD with 1920x1200 resolution
    • 10-bit color processing in 100% Rec 709
    • 1000nits of brightness
    • 4K & HDR compatible
    • 160-degree viewing angle

      Versatile I/O
    • Input: 1x 3G-SDI, 1x 3G-SDI In/Out, 1x HDMI 2.0, 1x Micro USB
    • Output: 1x 3G-SDI, 1x HDMI 2.0

      Power Input Options
    • 2mm barrel connector port
    • Included Sony L-Series dual battery bracket
    • Optional Gold Mount & V-Mount battery plate attachments (sold separately)

      Rugged Lightweight Housing
    • Anodized aluminum chassis
    • Featherlight weight: 1.1lbs (.53kg)
    • Ultrathin body width: 1.2in (3.35cm)


  • Specifications:

    • Environmental
    • Package Weight: 1.6lb
    • Dimensions: 4.67 x 1.32 x 7.09 inch
    • Compliance: FCC, IC, CE, RoHS
    • Operating Temperature: 30F to 100F
    • Storage Temperature: 0F to 120F
    • Mount Points: Four 1/4-20 Mount Points (Left, Right, Bottom, and Back)
    • Construction: Anodized aluminum chassis

      Display
    • Panel Type: IPS LCD Touchscreen
    • Diagonal Size: 7.02
    • Resolution: 1920x1200
    • Pixel Density: 323
    • Aspect Ratio: 0.6736111111111112
    • Active Area: 5.95 x 3.72
    • Brightness: 1000 Nits
    • Contrast: 1000:1
    • Gamut: 100% rec709
    • Color Depth: 10-bit Processing (8-bit panel)
    • Viewing Angle: 160
    • Backlight Type: LED
    • Adjustable Backlight: Yes

      Input Signal
    • 3G-SDI Input Types: YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100
    • HD-SDI Input Types: YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98
    • SD-SDI Input Types: YCC 4:2:2 @ 10-bits: 480i59.94, 576i50
    • HDMI Input Types: YCC 4:2:2 @ 12 bits, 8/10/12/16 bit color in RGB & YCC 4:4:4: 3840x2160 30p, 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94 , 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i50
    • Audio Input Types: HDMI & SDI - Monitor through Speakers in Front Bezel or Through Headphone Jack - Metering up to 8 channels

      Output Signal
    • 3G-SDI Output Types: YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100
    • HD-SDI Output Types: YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98
    • SD-SDI Output Types: YCC 4:2:2 @ 10-bits: 480i59.94, 576i50
    • HDMI Output Types: YCC 4:2:2 @ 12 bits, 8 bit color in RGB & YCC 4:4:4: 2160p30, 2160p29.97, 2160p25, 2160p24, 2160p23.98, 1080p120, 1080p119.88, 1080p100, 1080i120, 1080i119.88, 1080i100, 1080i60, 1080i59.94, 1080i50, 720p240, 720p239.76, 720p200
    • Audio Output Types: HDMI & SDI - Incoming Audio Stream is sent downstream via HDMI or SDI connection

      Connector Type
    • SDI: 1x BNC 3G input and 1x BNC 3G selectable input/output
    • HDMI: 1 input and 1 output: HDMI Type-D Receptacles (full size)
    • Audio: 1x 3.5mm 3-pin Stereo Headphone Jack
    • Power In: Barrel, 2.0mm ID, 5.5mm OD (center pin positive)
    • USB: 1x USB 2.0 Micro-B receptacle:

      Controls
    • Primary: Touch Screen
    • Record Capture: Image Capture Tool

      Power
    • Connector: Barrel, 2.0mm ID, 5.5mm OD (center pin positive)
    • Voltage: DC in - 10V minimum to 34V maximum, Battery terminals - 6.0V minimum to 16.8V max
    • Consumption: 17.3 watts (2160p30, 100% bright, tools enabled), (2.4A @7.2V battery, 1.4A @12V barrel, 0.7A at 24V barrel)
    • Batter Plate Included: L-Series standard (V Mount or Gold Mount optional accessories)
    • Power Supply: Recommend DC 12~15V at ~2.5 amp or greater
    • Battery Types: L-Series, V Mount, Gold Mount
    • Overload Protection: DC input Reverse polarity
    • Battery Chemistry: Li-ion
    • Battery Charging Time: Monitor does not support the charging of batteries

      Software
    • Pixel Zoom: 1.1-2.0x & 2.0-8.0x via swipe up/down. Infinitely adjustable via pinch & zoom
    • Frame Guides: Preset Aspect Ratios & Customizable
    • DSLR Scale: Canon 5DMkii & Canon 7D
    • Custom Scale: Yes (Underscan Only)
    • Anamorphic De-Squeeze: 0.75x, 1.33x, 1.5x, 1.66x, 2.0x, 2.5x
    • Image Rotate: Automatic or Manual Control
    • Image Flip: Automatic or Manual Control
    • Cross Conversion: Yes: HDMI -> SDI & SDI -> HDMI
    • Focus Assist: User Adjustable Color Style and Intensity


  • Item Includes:

    • 1x Indie 7
    • 1x Cleaning cloth
    • 1x Sony L Series battery bracket (Smart 7 Monitor series)


  • GTIN:

    0811786032273
