KanexPro SP-1X4A8K HDMI 1x4 Splitter with Audio 8k - HDMI 2.1 and HDCP 2.3 Compliant - 40Gbps Video Bandwidth Support

ITEM #: KAN-SP-1X4A8K MFG #: SP-1X4A8K

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

Our Price:

$429.95

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


SP-1X4A8K - Overview

The KanexPro SP-1X4A8K 8K HDMI 1x4 Splitter has the ability to distribute a single HDMI source signal to two display devices. This product supports video resolution of up to 8K at 60Hz and 4:2:0, and also features advanced EDID management and audio de-embedding functionality, with audio output available through both optical and analog ports. This versatile product has numerous applications, including demonstration, video conferencing, multimedia teaching, and any other occasions that require large-screen display.

  • Features:

    • HDMI 2.1 and HDCP 2.3 compliant
    • Support 40Gbps video bandwidth
    • Support video resolution up to 8K@60Hz 4:2:0 10bit, 8K@30Hz 4:4:4 10bit, 4K@120Hz 4:4:4 10bit
    • VRR, FVA, ALLM supported
    • Support HDR, HDR10, HDR10+, Dolby Vision, HLG pass through
    • Support HDMI audio formats: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
    • Built-in Equalizer, Retiming and Driver
    • Advanced EDID management
    • Support audio de-embedding function (output through the optical and analog port)
    • Compact design for easy and flexible installation

  • Specifications:

      Technical
    • HDMI Compliance: HDMI 2.1
    • HDCP Compliance: HDCP 2.3
    • Video Bandwidth: 40Gbps
    • Video Resolution:
      - Up to 8K @ 60Hz 4:2:0 10bit
      - 8K @ 30Hz 4:4:4 10bit
      - 4K @ 120Hz 4:4:4 10bit
    • Color Depth: 8/10/12-bit
    • Color Space: RGB, YCbCr 4:4:4/4:2:2. YUV 4:2:0
    • Audio Formats:
      - HDMI Input/Output: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
      - Audio De-Embedding Output: Optical: LPCM 2/5.1 CH, Dolby Digital 2/5.1 CH, DTS 2/5.1 CH Analog: PCM 2.0
    • ESD Protection: Human body model - ±8kV (Air-gap discharge) & ±4kV (Contact discharge)
    • Connection: 1x HDMI IN [Type A, 19-pin female]
    • Input Output:
      - 4x HDMI OUT [Type A, 19-pin female]
      - 1x OPTICAL [S/PDIF]
      - 1x L/R [3.5mm Stereo Mini-jack]
    • Control: 1x SERVICE [Micro USB, Update port]

      Mechanical
    • Housing: Metal Enclosure
    • Silkscreen Color: Black
    • Dimensions: 8.35" x 3.7" x 0.9" (212mm x 94mm x 23mm)
    • Weight: 1.18lbs (539g)
    • Power Supply:
      - Input: AC 100V - 240V 50/60Hz
      - Output: DC 12V/2.5A (US/EU standards, CE/FCC/UL certified)
    • Power Consumption: 9W (Max)
    • Operation Temperature: 32°F - 104°F (0°C - 40°C)
    • Storage Temperature: -4°F - 140°F (-20°C - 60°C)
    • Relative Humidity: 20% - 90% RH (non-condensing)

  • Item Includes:

    • 1x 8K HDMI 1x4 Splitter
    • 1x 12V/2.5A Multinational
    • 1x Power Supply
    • 1x User Manual
