Kramer TBUS-203xl(B) Pop-Up Table Mount Multi-Connection Solution - Black Sand Blasted Top

ITEM #: KR-TBUS-203XLB MFG #: TBUS-203XL(B)

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the KR-TBUS-203XLB

TBUS-203XL(B) - Overview

The Kramer TBUS-203xl is a furniture-mounted pop-up connection bus that is easily installed into a table or podium top. The TBUS-203xl interface enables you to connect any equipment to systems installed in a room via five single inserts or two dual inserts and one single insert.

Please Note: The power socket module is not included. Purchase the country-specific module separately. The TBUS enclosure, power socket, power cord & connector inserts are all purchased separately.

Perfect for:
Boardrooms
Conference rooms
Training rooms

  • Features:

    • Pneumatic Lift - Easy opening & closing by pressing down gently on the cover. When not in use, it lowers flush with the table.
    • Power Input - Universal, USA, European and many other worldwide power sockets available.
    • Elegant and Rugged Rectangular Design - The sturdy and attractive anodized aluminum enclosure provides maximum connectivity in the smallest possible footprint, and at the same time is cost effective and easy to install.
    • Installation - Requires tools and expertise to cut a 21.2cm x 12.2cm (8.4" x 4.8") rectangular hole in the surface of the furniture. Maximum table thickness is 7.6cm (3").


  • Specifications:

    • PORTS: 5 blank inserts.
    • POWER SOCKET ASSEMBLIES: USA 100-220V AC, 50/60Hz, 5A per outlet;
    • Germany and EU 100-240V AC, 50/60Hz, 5A per outlet;
    • Belgium and France 100-240V AC, 50/60Hz, 5A per outlet;
    • Italy 100-240V AC, 50/60Hz, 5A per outlet;
    • Australia 100-240V AC, 50/60Hz, 5A per outlet;
    • Israel 220V AC, 50/60Hz, 5A per outlet;
    • South Africa 220V AC, 50/60Hz, 5A per outlet;
    • Switzerland 220V AC, 50/60Hz, 5A per outlet;
    • UK 220V AC, 50/60Hz, 5A per outlet;
    • Brazil 220V AC, 50/60Hz, 5A per outlet.
    • FUSE RATING: T 6.3A 250V.
    • OPERATING TEMPERATURE RANGE: +5° to +45°C (41° to 113°F).
    • OPERATING HUMIDITY RANGE: 10 to 90% RHL, non-condensing.
    • STORAGE TEMPERATURE RANGE: -20° to +70°C (-4° to 158°F).
    • STORAGE HUMIDITY RANGE: 5 to 95% RHL, non-condensing.
    • DIMENSIONS: 14.5cm x 13.2cm x 17.3cm (5.71" x 5.2" x 6.81") W, D, H.
    • WEIGHT: 1.4 kg (3.09 lbs) approx., 1.65kg (3.64 lbs) approx. with mounting brackets, 1.9 kg (4.19 lbs) approx. packed product.
    • INCLUDED ACCESSORIES: Cut out metal template.
    • OPTIONS: Power socket kits, power cord.


  • Item Includes:

    • TBUS-203XL(B) Table Box
    • Cut out metal template


  • Warranty:

    • Limited 7 Year Warranty


  • GTIN:

    7291063075873
