Kramer TBUS-201XL(B) Pop-Up Table Mount Multi-Connection Solution - Black Sand Blasted Top

ITEM #: KR-TBUS-201XL MFG #: TBUS-201XL(B)

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Kramer
Free Shipping with $49 Minimum Order
Availability: Sold Out
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

TBUS-201XL(B) - Overview

Kramer's TBUS-201xl provides an extremely simple, affordable and elegant single-push pop-up multi-connection boardroom solution. By pressing down gently on the lid, the unit opens and closes pneumatically. TBUS-201xl is fast and easy to install and flexible to configure. It customizes to your own needs and is intuitive to operate.


Requires a Country Specific Power Socket Module & Power Cord - Purchased Separately

Perfect for
Boardrooms
Conference rooms
Classrooms
Training facilities

  • Features:

    • Elegant in-table compact solution
    • Avoids the tabletop "cable jungle"
    • Easy to install
    • Flexible to configure and customize
    • CE qualified
    • Pneumatic Lift - Easy opening & closing by pressing down gently on the cover. When not in use, it lowers flush with the table.
    • Power Input - Universal, USA, European and many other worldwide power sockets available.
    • 4 Fixed Inputs - 15-pin HD, HDMI, 3.5mm & Ethernet.
    • Rugged Rectangular Design - The sturdy and attractive anodized aluminum enclosure provides maximum connectivity in the smallest possible footprint, and at the same time is cost effective.
    • Installation - Requires tools and expertise to cut a 133mm x 120mm (5.2" x 4.7") rectangular hole in the surface of the furniture involved. Maximum table thickness is 7.6cm (3").
    • Note - The power socket module is not included. Purchase the country-specific module separately.


  • Specifications:

    • PORTS
    • 1 HDMI connector, 1 Ethernet RJ-45 connector, 1 15-pin HD connector, 1 3.5mm mini jack

    • POWER SOCKET ASSEMBLIES
    • USA and Universal 100-240V AC, 50/60Hz, 5A per outlet; 100-220V AC, 50/60Hz, 5A per outlet
    • Germany and EU 100-240V AC, 50/60Hz, 5A per outlet
    • Belgium and France 100-240V AC, 50/60Hz, 5A per outlet
    • Italy 100-240V AC, 50/60Hz, 5A per outlet
    • Australia 100-240V AC, 50/60Hz, 5A per outlet
    • Israel 220V AC, 50/60Hz, 5A per outlet
    • South Africa 220V AC, 50/60Hz, 5A per outlet
    • Switzerland 220V AC, 50/60Hz, 5A per outlet
    • UK 220V AC, 50/60Hz, 5A per outlet
    • Brazil 220V AC, 50/60Hz, 5A per outlet

    • OPERATING TEMPERATURE RANGE
    • +5° to +45°C (41° to 113°F)

    • OPERATING HUMIDITY RANGE
    • 10 to 90% RHL, non-condensing

    • STORAGE TEMPERATURE RANGE
    • -20° to +70°C (-4° to 158°F)

    • STORAGE HUMIDITY RANGE
    • 5 to 95% RHL, non-condensing


  • Item Includes:

    • TBUS-201XL(B)
    • Cardboard Template


  • Warranty:

    • Limited 7 Year Warranty


  • GTIN:

    7291063059392
