Canare L-5CFW 18 AWG 75 Ohm Flexible Coaxial Digital Video Cable - Blue - 984 Foot/300M

Name: Canare L-5CFW 18 AWG 75 Ohm Flexible Coaxial Digital Video Cable - Blue - 984 Foot/300M
Brand: Canare
SKU: L-5CFWBE-984
Price: 863.28 USD
Availability: PreSale

ITEM #: L-5CFWBE-984 MFG #: L-5CFWBE 300M

Canare

List Price:

$959.20

Our Price:

$863.28

Add to Wish List Leasing Options

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

L-5CFWBE 300M - Overview

The Canare L-5CFWGN-984 is a 75 ohm flexible digital video coaxial cable. It features a solid copper center conductor and dual copper braid for flexibility in the cable.

Suggested Connector: BCP-H3175 Ohm Digital Video Flexible Coaxial Cable - Per Foot - Black

Applications Include:
- HD-Serial Digital Video
- Mobile Applications
- HDTV Upgrades
- Broadband Facilities
- SMPTE 259M, 292M,424M

Features:
- HD-Serial Digital Video
- Mobile Applications
- HDTV Upgrades
- Broadband Facilities
- SMPTE 259M, 292M,424M
- Solid Copper Center Conductor
- Foam PE Dielectric
- Dual Copper Braid for Flexibility
- 2 Sizes Available
- Precision Coax 100% Sweep Tested
Specifications:
- Standard Length: 984 Feet (300 Meters)
- Weight: 17.66lbs (8.1kg)
- Nominal O.D.: .303" (7.7 mm)
- Conductor Material: Bare copper
- Dielectric Insulation Type: Foam PE
- Insulation O.D: 0.193" (4.9mm)
- Shield Material Coverage (mm/ends/carrieers): 0.12TA/9/24 (96% or more)
- Conductor D.C.R: 2.3Ω/100m
- Shield D.C.R: 0.5Ω/100m
- Nominal Capacitance: 17 @ 1KHz (55 pF/m)
- Nominal Impedance: 75Ω
