LevelOne FCS-5044 PTZ IP Network Camera - 2 MP - 10x Optical Zoom - 802.3af PoE - IR LEDs - Indoor/Outdoor

FCS-5044 - Overview

• Features:

  • 2-Megapixel (1920 x 1080) high-definition resolution
  • Supports 10x optical zoom
  • Supports 150° pan and 95° tilt
  • Compression: H.264/MPEG-4/MJPEG
  • Features WDR (Wide Dynamic Range) to enhance visibility under extremely bright or dark environments
  • Power support: PoE (IEEE 802.3af)
  • Removable IR-cut filter for day and night surveillance
  • Supports 2 video streams simultaneously
  • Supports motion detection and event notification via e-mail or FTP
  • Built-in infrared LEDs for night viewing up to 40m
  • Built-in microphone and external speaker for 2-way audio communication
  • Dual power support: 12VDC/PoE (IEEE 802.3af)
  • Free video surveillance and CMS (Central Management System) software with 64-channel license


• Specifications:

  • Camera Specification
  • Type 1/2.8 Sony CMOS sensor IMX236,
  • Resolution: 1920x1080

    Lens
  • 10X optical zoom lens, auto iris, auto focus
  • f = 4.9~ 49mm, F1.8~3.0
  • Fov(D), 66.6° ~ 7.2°

    System
  • RAM: 4G bit DDRIII
  • ROM: 16MB Flash ROM

    Infrared LED
  • High power IR Leds, 30~40 M visible
  • Auto/Manual mode

    Protocol
  • TCP/IP, HTTP,UDP, SMTP, FTP, DDNS
  • UPnP, Telnet, NTP, PPPoE, RTSP
  • RTP,RTCP,DHCP and DNS
  • 10 baseT or 100 baseT Fast Ethernet auto negotiation

    Video Resolution
  • Up to 30 frames at 1920*1080, 1280x1024
  • 1280x800, 640x480, 320x240 and 176x144

    Audio
  • G.711/AMR/AAC
  • Support 2 way audio

    Algorithm Supported
  • H.264/MPEG4/MJPEG dual codec for
  • streaming video
  • JPEG for still image

    I/O Interface
  • RJ-45
  • DI
  • Audio in
  • Audio out
  • Video out
  • DC Power
  • SD(inside camera)

    Pan/Tilt Angle
  • Support multi - direction movement
  • Pan: 150°(-75°~75°)
  • Tilt: 95°(-75°~20°)

    EMI & Safety
  • CE, FCC

    Power
  • Input: 100-240VAC, 50/60Hz, 0.7A
  • Output: 12VDC, 1.5A
  • Consumption: Max 10W
  • Support 802.3af compliant Power over
  • Ethernet

    Dimensions
  • 3.9 x 5.04 x 4.88 inch

    Operating Environment
  • Temperature: -20 - 50°C
  • Humidity: 85% RH

    Weight
  • NET: 1.7lbs
  • With bracket: 2.2lbs


• Item Includes:

  • 1x LevelOne FCS-5044 PTZ IP Network Camera - 2 MP - 10x Optical Zoom - 802.3af PoE - IR LEDs - Indoor/Outdoor
