14-2C-DB-BLK - Overview

Liberty's 14-2C-DB-BLK 2 conductor 14 AWG stranded, twisted, and unshielded cable NEC type CL3, Suitable for Direct Burial and Sunlight Resistant. Product manufactured compliant to the requirements of UL13 for installations and applications in accordance with NEC article 725.

  • Features:

    • 19-strand annealed bare copper conductors
    • Low density polyethylene insulation
    • Twisted, unshielded
    • UV stabilized PVC jacket
    • NEC CL3, direct burial, sunlight resistant, RoHS compliant
    • 1000 foot spools


  • Specifications:

    • 19-strand annealed bare copper conductors
    • AWG: 14
    • Diameter: 0.069" / 1.75mm
    • DC resistance: 2.76 Ω / 1000' / 9.05 Ω/KM
    • Mutual capacitance: 20.0 pF/FT / 65.47 pF/M
    • Impedance: 78 Ω
    • Inductance: 0.16µH/FT / 0.52µH/M
    • Velocity of Propagation: 55%
    • Voltage rating: 300V
    • Maximum current: 8A@25°C
    • Reel: 1000' / 305M
    • Weight: 57 Lbs/1000' / 85 Kg/KM
