Sescom Mic Cable 2-Conductor High Performance - Per Foot

ITEM #: MIC-BC MFG #: MIC-BC

Primary Image
Sescom
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$0.66

Our Price:

$0.60

Add to Wish ListLeasing Options
Availability: In Stock
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

MIC-BC - Overview

Sescom's ideal general purpose professional microphone cable that's tough, yet flexible. 95% copper braid shield with 2-Conductor 24 AWG stranded copper wire. Flexible anti-static matte black jacket. Ideal for stage, sound and field use for all applications. Currently being used by our many professional audio customers.

  • Features:

    • 2 Conductor
    • 24 AWG
    • Stranded Bare Copper
    • Polypropylene Insulated
    • Overall Serve Shielded
    • PVC Jacketed


  • Specifications:

    • AWG Size and Stranding: 24 AWG 16 Strands 36 AWG
    • Conductor Material: Bare Annealed Copper
    • Insulation Material: Polypropylene
    • Insulation Wall Thickness: .013" Nominal
    • Insulation Diameter: .050" +/- .002"
    • Color Code: Blue Paired with Red
    • Shield Material: Bare Annealed Copper Serve
    • Shield Coverage: 95% Nominal
    • Jacket Material: Matte Finish Polyvinyl Chloride
    • Jacket Wall Thickness: .055" Nominal
    • Jacket Diameter: .230 +/- .005"

      Electrical Specifications:
    • Capacitance Between Conductors: 21 pF/ft @ 1 kHz
    • Capacitance Conductor to Shield: 37 pF/ft @ 1 kHz
    • Characteristic Impedance: 70 ohms @ 1 MHz
    • Resistance at 20C: 23 ohms/1000 ft.


  • Warranty:

    • 1 Year
