C-008HBAA5KM - Overview

Providing the durability you expect from OCC, we offer a wide variety of broadcast products including SMPTE cables, enclosures, and assemblies. The TACTICAL option utilizes the OCC Ultra-Fox™ Plus deployable buffer system with the combination of a triple thickness 500 micron diameter acrylate coating together with a hard elastomer 900 micron tight buffer for maximum fiber protection. This cable is ideal for harsh outdoor deployable applications.

  • Features:

    • Ideal for harsh outdoor deployable applications
    • Utilizes the Ultra-Fox Plus buffer system for maximum fiber protection-same fiber as used in OCC's military grade products
    • Fully SMPTE 311 compliant

  • Specifications:

    • 2 Fiber count
    • 4 Power Conductors: 20 AWG19 Strand Class C Annealed Tinned Copper PE Insulated
    • 2 Control Conductors: 24 AWG 7 Strand Class B Annealed Tinned Copper PE Insulated
    • Strength member: 16 AWG Galvanized Steel Polyurethane Insulated-Purple
    • PN: C-008HBAA5KM
    • Diameter: 9.2 mm (0.36 in)
    • Weight: 144 kg/km (97 lbs/1000’)
    • Minimum Bend radius: 5.1 cm (2 in)
    • Max cable attenuation (dB/km): 0.5/0.5
    • Jacket material: Polyurethane
