OCC C-006HBAD5KB SMPTE FLEX 7.8mm Fiber Cable - Black - Per Foot

ITEM #: OCC-C-006HBAD5FT MFG #: C-006HBAD5KB FT

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$3.00

Our Price:

$2.75

Availability: In Stock
iAvailability Description Popup


C-006HBAD5KB FT - Overview

Providing the durability you expect from OCC, we offer a wide variety of broadcast products including SMPTE cables, enclosures, and assemblies. OCC's FLEX cable is flexible enough to let cameras move quickly and frequently. The FLEX cable utilizes the OCC Ultra-Fox™ Plus deployable buffer system with the combination of a triple thickness 500 micron diameter acrylate coating together with a hard elastomer 900 micron tight buffer for maximum fiber protection.

  • Features:

    • Compatible with SMPTE 311 Standards
    • Rugged, cut-resistant, abrasion-resistant polyurethane Jacket
    • Lightweight (lightest weight OCC SMPTE cable offering)500µm acrylate fiber for added durability - same fiber as is used in OCC's military grade products!
    • Aramid central strength member for increased flexibility over cables made with steel strength members
    • Cotton filler and nylon overwrap help minimize cable migration during flexing
    • 95% braided shield coverage

  • Specifications:

    • 2 Fiber count
    • 2 Power Conductors: 16 AWG 65 Strand Class C Annealed Tinned Copper PE Insulated
    • 2 Control Conductors: 24 AWG 19 Strand Class B Annealed Tinned Copper PE Insulated
    • Strength member: Jacketed aramid
    • PN: C-006HBAD5KB
    • Cable diameter: 7.8 mm (0.31 in)
    • Weight: 100kg/km (67 lbs/1000')
    • Minimum bend radius: 3.9 cm (1.5 in)
    • Max cable attenuation (dB/km): 0.5/0.5
    • Jacket material: Polyurethane
