OCC DCC2488/110SIX Cat6 24-Port Rack Mount Patch Panel

ITEM #: OCC-DCC2488110SX MFG #: DCC2488/110SIX

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$147.98

Our Price:

$134.52

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


DCC2488/110SIX - Overview

Cat 6, 24 Port Patch Panel, When Category 6 was introduced to the market, OCC brought a product offering that was designed to exceed industry expectations and surpass the governing standards. OCC created Category 6 connectivity components that offered patented technology and guaranteed bandwidth performance. OCC's DCC2488/110SIX Category 6 patch panels were no exception. Developed to offer true performance, their Category 6 patch panels are truly standards compliant.

  • Features:

    • Available in 24 & 48 port
    • Category 6 component compliant
    • 610 punch-down block
    • ETL verified to TIA-568-C.2 Category 6
    • Power-safe modular jack contacts
    • OCC patented PCB technology
    • Backward compatible; Cat 3 & 5e
    • Mounting flexibility
    • Removable cable strain-relief bar
    • Patch panels are available in both flat and angled configurations
    • All-steel panel ensures panel rigidity and reliable terminations
    • Universal T568A/B wiring for easy installation
    • 6-port component modules
    • Write-on label fields
    • Rigid box-section panel construction
    • Supports all IEEE Power over Ethernet (PoE) standards
    • Insulation resistance: 500MΩ minimum
    • Dielectric withstand: 1000 VAC RMS or 1414 VDC
    • DC current rating: 1.5 A per conductor at 20°C ambient de-rated to 0.75 A at 60°C ambient

  • Specifications:

    • Rack Mount Patch Panel
    • 568A/B Wired
    • 24-Port
    • Category 6
    • 1RU
    • Rack Mount Patch Panel
    • 568A/B Wired
    • 24-port


DCC2488/110SIX - Required Accessories
