Plura PBM-224-4K-DUAL Dual Integrated 24inch 4K Monitors - Customized Monitoring Solution (4096 x 2160)

PBM-224-4K-DUAL - Overview

• Features:

  • PBM-224-4K-DUAL, 2 x 24? 4K - UHD Panels
  • Decode ST-2110 and ST-2022 IP streams with "PIPM" Plura Software Stack IP Platform module
  • Supports Coaxial 12G/3G/1.5G BNC I/O connectivity
  • Supports Coaxial SFP I/O connectivity
  • Supports IP SFP+ over fiber decoding "ST-2110 & ST-2022" with any Third-Party H/W decoder
  • 2 x SFP+ cages supporting 12G/10G/3G/1.5G SDI
  • 4 x 12G/3G/1.5G input ports
  • 4 x 12G/3G/1.5G output ports
  • *"PIPM" Plura Software Stack IP Platform - OPTIONAL
  • 2 x HDMI 2.0a
  • 10 bit panel color depth
  • Supports up to 4096 x 2160 resolutions
  • HDR (High Dynamic Range) capabilities
  • PQ (SMPTE ST 2084) & HLG (Hybrid Log Gamma)
  • Side by side HDR / SDR Processing
  • RGB 12 bit Digital Signal Processing
  • 178 degree Viewing Angle Display
  • Gamma Selectable ( 0.8 - 3.0)
  • Color Temperature - User, VAR, Adjustable (11000K TO 3200K)
  • (ICAC) - Plura Intelligent Connection for Alignment & Calibration
  • 3D LUT (ITU-R BT 2020, Native, BT.709, SMPTE-C, EBU, NTSC, D-Cinema)
  • Display Advanced Waveform & Vector Scope simultaneously with line select
  • Various and User defined Markers Display & Safe Area
  • Programmable 3 User Front Pushbutton Controls & GPI
  • Closed Caption (608/708) - North American Market
  • Cutting edge De-interlacing and scaling Technology
  • Fast Response Time for high motion video
  • Internal Monitor Display (IMD)
  • Ethernet & RS232 Remote Control
  • Ember+ compliant control system capabilities
  • Underscan / Overscan / Normal / Zoom
  • Pixel to Pixel Mode, Tally, DC opeartion
  • False Color and Peaking Filter / Focus Assist
  • Video Range test with adjustable Y & C values
  • Display LTC & DIVTC time code with line select
  • Embedded Audio input, Digital Audio Decoding
  • Internal Pattern Generator and Wall Control System


• Specifications:

  • Weight: 44 lbs
  • Dimensions: 43.1 x 13.2 x 2.6 in
  • Screen Size: 2 x 24inch
  • Style: Desktop
  • Screen Resolution: 3840x2160
  • Backlight: LED
  • Color Depth: 10bit
  • Features: 4K/UHD, HDR, IP, SFP Modules Compatibility
  • Remote Control Features: Ember+, Ethernet, RS232, Wall Control System
  • ICAC: Yes
  • H/W Decoding: ST-2022, ST-2110
  • S/W Decoding: ST-2022, ST-2110
  • Video: 12G, 3G, DVI, HD-DL, HDMI, HDSDI
  • Audio: Embedded Digital Audio
  • Additional Features: Closed Caption, Vectorscope, Waveform
  • Housing: VESA (100x100), (100x200), (100x300), (100x400), (100x500), (100x600) & (100x700)
