Techflex PTN0.13 1/8-Inch Flexo PET Expandable Tubing - Blue - 100-Foot

ITEM #: PET1-C-BE MFG #: PTN0.13BL 100FT

Primary Image
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$21.00

Our Price:

$17.50

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


PTN0.13BL 100FT - Overview

The FLEXO PET (PT) grade is used in electronics, automotive, marine and industrial wire harnessing applications where cost efficiency and durability are critical.The unique braided construction and wide expandability allows quick and easy installation over large connectors and long runs. PT can be found in applications ranging from small office/home office to high tech wire and cable harnesses.

The wide range of available colors and sizes allows easy and systematic color coding in complex wiring and cabling schemes.

PT is braided from 10 mil polyethylene terephthalate (PET) monofilament yarns. The material has a wide operating temperature range, is resistant to chemical degradation, UV radiation, and abrasion. The sleeving cuts easily and cleanly with a hot knife and once installed, will beautify and protect any wire, hose or cable application.

  • Specifications:

    • Monofilament Thickness (ASTM D-204): 0.010
    • Flammability Rating: UL-94
    • Recommended Cutting: Hot Knife
    • Colors: 28
    • Wall Thickness: 0.025
    • Tensile Strength - Yarn (ASTM D-2265) lbs.: 7.5
    • Abrasion Resistance: Medium
    • Specific Gravity: 1.38
    • Moisture Absorption % (ASTM D-570): 0.1 - 0.2
    • Minimum Continuous Temperature: -94°F/-70°C
    • Maximum Continuous (MIL-I-23053) Temperature: 257°F/125°C
    • Melt (ASTM D-2117)Temperature: 482°F/250°C
