Plura PBM-217-4K 17 Inch - 4K Broadcast Monitor (3840 x 2160) - 4K - HDR Capability

ITEM #: PLUR-PBM-217-4K MFG #: PBM-217-4K

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$8,399.00

Our Price:

$7,559.10

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


PBM-217-4K - Overview

The PBM-4K Series is a complete portfolio of 4K monitors in alignment with increased industry demand. Available in multiple sizes from 24 up to 84 inches, the Plura PBM-4K series bring the exceptional built-in feature set Plura monitors are known for, maintaining quality and performance to give production facilities an edge in Ultra HD monitoring.

The Plura PBM-4K is a great tool for all UHD/4K, 3G broadcast systems and all other wide-range industries. The PBM-4K series was designed and engineered for simple operation and future flexibility. The platform is built around a powerful FPGA chipset. The core of this platform is based on fully programmable architecture. Future proof expansion (i.e. additional features and functionalities) can and will be implemented in the field via the Ethernet interface.

The PBM-4K series comes in multiple sizes; 24, 32, 43, 49, 55, 65 and 84 inches, all sizes offer the extensive and well-know Plura prominent features. PBM-4K Series supports up to 4096 x 2160 resolutions, focuses on delivering the highly detailed, accurate color representation and stunning picture consistency that high-end production applications require. The PBM-4K series offers HDR Display capabilities supporting PQ (ST-2084) & HLG standards.

  • Features:

    • 1 x HDMI 2.0
    • 2 x 12G, 6G, 3G, 1.5G
    • 1 x SFP Slot supporting Multiple I/O Standards
    • Quad 3G SQ and 2SI with 4KXpress
    • 10 bit panel color depth
    • Supports up to 4096 x 2160 resolutions
    • HDR (High Dynamic Range) capabilities
    • PQ ( SMPTE ST 2084 ) & HLG ( Hybrid Log Gamma )
    • Side by side HDR / SDR mode
    • RGB 12 Bit Digital Signal Processing
    • 178° Viewing Angle Display
    • Gamma Selectable (0.8 - 3.0)
    • Color Temperature - User, VAR, Adjustable (11000K TO 3200K)
    • (ICAC) - Plura Intelligent Connection for Alignment & Calibration
    • 3D LUT ( ITU-R BT 2020, Native, BT.709, SMPTE-C, EBU, NTSC, D-Cinema, 709)
    • Display Advanced Waveform & Vector Scope simultaneously with line select
    • Various and User defined Markers Display, Safe Area in HD & SD
    • Programmable 3 User Front Pushbutton Controls & GPI
    • Closed Caption (608/708) - North American Market
    • Cutting edge De-interlacing and Scaling Technology
    • Fast Response Time for high motion video
    • Internal Monitor Display (IMD)
    • Ethernet & RS232 Remote Control
    • Underscan / Overscan / Normal / Zoom

  • Specifications:

    • Input/Output
    • SDI Input: 2EA, Serial Digital, 12G/3G/HD-SDI BNC Jack
    • SFP Port: 1EA, SFP Optical and/or Electrical
    • HDMI: 1EA, HDMI, 19pin Female
    • SDI Output: 2EA, Serial Digital, 12G/3G/HD-SDI BNC Jack

      Digital Input Format
    • SMPTE-ST 2082M: 3840x2160 (23.98/24/25/29.97/30/50/59.94/60p)
    • SMPTE 428.1M: 2048x1080P (24/25)
    • SMPTE-425M AB(3G): 1920x1080P (60/59.94/50/30/29.97/25/24/23.98/30sf/29.97sF/25sF/24sF/23.98sF) / 1080i (60/59.94/50)
    • SMPTE-260M: 1920x1035i(60/59.94)
    • SMPTE-274M/292M: 1920x1080i (60/59.94/50); 1920x1080P (30/29.97/25/24/24sF/33.98/23.98sF )
    • SMPTE 296M: 1280x720P (60/59.94/50)
    • SFP: 12G / 6G / 3G / 1.5G
    • UHD HDMI 2.0: 480P / 720P /1080P /2160P

      Audio Input/Output
    • SDI Audio Input: Embedded HD/SD-SDI Audio
    • HDMI Audio Input: Embedded Audio
    • Speaker Output: Internal Speaker (Stereo) 3W + 3W
    • Ear-Phone Output: 1EA, L/R Stereo, 3.5mm pin jack

      I/O Port
    • GPI: RJ-45 8 Pin (Programmable for General Purpose Input)
    • Ethernet: ETHERNET (System Control) Firmware upgrade
    • USB: Firmware upgrade
    • RS232: D-sub 9 pin female /Firmware Upgrade

      LCD
    • Size: 17" Diagonal
    • Aspect Ratio: 16 : 9
    • Resolution: 3840 x 2160
    • Display Color: 1.07 Billion Colors
    • Brightness: 350cd/m2
    • Viewing Angle: Horizontal: 178 (Typ.) Vertical 178 (Typ.)

      General
    • Power Requirements: AC 100V ~ 240 V (60/50 Hz)
    • Operating Temperature: 0°C - 40° C (32° ~ 104°F)
    • Storage Temperature: -10°C - 80° C (14° ~ 176°F)
    • Humidity: 10% RH ~ 85%RH ( Non Condensed)
