PTZOptics PT-WC-PP-G1 Wireless Cable Pre-Paired Kit

ITEM #: PTZ-PT-WC-PP-G1 MFG #: PT-WC-PP-G1

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the PTZ-PT-WC-PP-G1

PT-WC-PP-G1 - Overview

The PTZOptics PT-WC-PP-G1 WirelessCable is a wireless data transmission system that functions just like a Ethernet cable. With a maximum transmission distance of 400m between 2 paired units, you can connect any device that utilizes a LAN connection. Multiple devices can be Daisy-Chained to increase the distance up to 1600m. The WirelessCable will make set up a breeze, allowing you to connect any device to your network without a physical cable.

  • Features:

    • Supports multi-level cascading
    • Supports a wide range of applications in wireless communication, live video, etc.
    • Up to 300Mbps wireless transmission bandwidth
    • 4x4 MIMO beamforming technology
    • 1/4-20 mounting screw on bottom and side of unit
    • Portable and easy to install
    • Infrastructure Mode
    • Daisy-Chain Mode
    • WPA2-AES & WPA2 + WPA Encryption


  • Specifications:

    • General
    • Frequency: 4.90 - 5.85 (GHz)
    • Bandwidth: 40MHz
    • Protocol: 802.11a/n
    • Receive Sensitivity: ≤ -70dBm
    • Transmitter Power: 17dBm
    • Max Speed Per Link: 300Mbps
    • Max Distance Between Units: 400m (Line of sight)
    • Daisy Chain Unit: Maximum 5 Total units
    • Infrastructure Mode: Limit 4 to 1

      Physical
    • Power Supply DC in: (6 ~ 17V) 2A (Max)
    • Dimensions (LxWxH) (No Bracket): 4.29 x 1.06 x 5.12" (109 x 27 130mm)
    • Dimensions (LxWxH) (Bracket): 8.63 x 7.86 x 2.25" (219.2 x 199.6 x 57.6mm)
    • Operating Temperature: 0° to 40°C (32° to 104°F)
    • Storage Temperature: -20° to 60°C (-4° to 140°F)
    • Weight: 1.54Lbs (0.7kg)


  • Item Includes:

    • 2x WirelessCable AP/ST
    • 1x Power Adapter + Cord
    • 1x LAN Cable
    • 1x Antennas (4)
    • 1x User Manual
    • 1x Mounting Base


  • Warranty:

    • 1 Year


  • GTIN:

    0737993162179
