Cobalt Digital RM20-9433EMDE-OE-C-HDBNC 20-Slot Frame Rear I/O Module 3G/HD/SD-SDI Fiber-Optic OE Receiver

RM20-9433EMDE-OE-C-HDBNC - Overview

• Features:

  • (2) SDI/ASI/MADI coaxial In/Out (Coax-A I/O and Coax-B I/O)
  • (1) Fiber Out (LC connector)
  • (6) DA Out coaxial


• Specifications:

  • Power
  • <18 Watts>
    SDI/Fiber Inputs/Outputs
  • (1) 75ohm BNC inputs
  • (1) 75ohm BNC output
  • SDI Receive Cable Length (1694A): 120m/180m/360m (3G/HD/SD)
  • SDI Return Loss: >15 dB up to 1.485 GHz; >10 dB up to 2.970 GHz
  • Note: SDI Return loss and receive cable length are affected by rear I/O module used. Specifications represent typical performance.
  • Alignment Jitter: 3G/HD/SD: < 0.3/0.2/0.2 UI
  • Timing Jitter: 3G/HD/SD: < 2.0/1.0/0.2 UI
  • (1) Fiber input; LC connector
  • Receive Sensitivity: -23 dBm; 1260 to 1620 nm
  • SDI Formats Supported: SMPTE 259M, SMPTE 292M, SMPTE 424M
    Analog Audio Specifications
  • Input Impedance: >10 k?
  • Reference Level: -20 dBFS
  • Nominal Level: +4 dBu
  • Input Clip Level: +24 dBu (0 dBFS)
  • Freq. Response: ±0.2 dB (20 Hz to 20 kHz)
  • SNR: 115 dB (A weighted)
  • THD+N: -96 dB (20 Hz to 10 kHz)
  • Crosstalk: -106 dB (20 Hz to 20 kHz)
  • Output Impedance: < 50 ?
  • Max. Output Level: +24 dBu (0 dBFS)
