StarTech PEX1000SFP2 PCIe GbE Fiber Card w/ Open SFP - PCI Express SFP Adapter

ITEM #: ST-PEX1000SFP2 MFG #: PEX1000SFP2

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$199.99

Our Price:

$199.62

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


PEX1000SFP2 - Overview

The StarTech PEX1000SFP2 PCI Express Gigabit Fiber Network Card lets you connect a PCI Express-based computer directly to a fiber optic network using the Gigabit SFP of your choice.

This Gigabit fiber card adapts to your network fiber connection and distance requirements to offer flexible configuration via an open SFP slot, and is compatible with most Gigabit SFP transceivers. With broad SFP compatibility the fiber network card lets you use your preferred SFP, giving you more options to connect your computer directly to a fiber network.

With fiber connectivity, your network is not susceptible to electronic interference, often problematic with standard RJ45 copper networks, making this versatile fiber card ideal for secure network setups.

Plus, the card is equipped with a standard profile bracket and includes a low-profile/half-height bracket, perfect for installation in small form-factor computers or 1U server and rackmount applications.

Applications:
Ideal for secure setups - a direct fiber connection means no electronic interference, which can be a problem with RJ45 network cards
Perfect for remote embedded industrial monitoring systems, and high-speed video surveillance
Retain full Gigabit network speeds to a remote terminal over longer distances than copper cabling

  • Features:

    • Compatible with most Gigabit SFP modules
    • Supports Full/Half-duplex Auto-Negotiation, Auto-MDI/MDIX
    • Includes low-profile/half-height installation bracket

  • Specifications:

    • Hardware
    • Bus Type: PCI Express
    • Card Type: Standard Profile (LP bracket incl.)
    • Chipset ID: Realtek - RTL8168E
    • Marvell - 88E1111B1
    • Industry Standards: IEEE802.3z 1000BASE-SX/LX, IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding, IEEE 802.3x full duplex flow control, RFC 1157 SNMP v1
    • Interface: Fiber Ethernet
    • Ports: 1

      Performance
    • Auto MDIX: Yes
    • Buffer Size: 48 KB
    • Compatible Networks: 1000 Mbps (1 Gbps)
    • Full Duplex Support: Yes
    • Maximum Data Transfer Rate: 2000 Mbps (2 Gbps) - Full-Duplex
    • MTBF: 770,619 hours

      Connector(S)
    • Connector Type(s): 1 - PCI Express x1 Male
    • External Ports: 1 - SFP Slot Female

      Software
    • OS Compatibility: Windows® XP, Vista, 7, 8, 8.1, 10
    • Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016
    • Mac OS X® 10.5 to 10.9
    • Linux 2.4.x to 4.11.x LTS Versions only
    • Microsoft Hyper-V®

      Indicators
    • LED Indicators: 1 - Link (Green)
    • 1 - Activity (Yellow)

      Power
    • Power Consumption (In Watts): 3.2W Max

      Environmental
    • Humidity: 5 to 95% RH (Non-Condensing)
    • Operating Temperature: 0° to 45°C (32° to 113°F)
    • Storage Temperature: -20° to 70°C (-4° to 158°F)

      Physical Characteristics
    • Height: 4.6" (11.8cm)
    • Length: 5" (12.8cm)
    • Width: 0.7" (18mm)
    • Weight of Product: 2oz (57g)

      Packaging Information
    • Height: 2" (52mm)
    • Length: 8.5" (21.7cm)
    • Width: 6.7" (17.1cm)
    • Weight: 7.1oz (200g)

  • Item Includes:

    • 1x 1 Port PCI Express Gigabit SFP Network Card
    • 1x Low-Profile Bracket
    • 1x Driver CD
    • 1x Instruction Manual

  • Warranty:

    • 2 Years

  • GTIN:

    0065030857383
