Turtle TAV-D2USB-PRO Dante Pro Dual Channel USB-B I/O Adapter - TAA Compliant

ITEM #: TAV-D2USBPRO MFG #: TAVD2USBPRO

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

Our Price:

$199.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


TAVD2USBPRO - Overview

Experience flawless bi-directional conversion between two-channel USB audio and Dante 2CH digital audio with the Turtle AV Dante Pro Dual Channel USB-C I/O Adapter. This versatile adapter is USB audio device class 1.0/2.0 compatible, supporting USB output up to 24bit/192KHz and input up to 24bit/96KHz. With Dante audio sampling rates of 24bit at 44.1, 48, 88.2, and 96KHz, it delivers exceptional audio quality. The configurable Dante audio delay (1, 2, or 5 milliseconds) ensures precision in any setup. Power by PoE or USB-C, for maximum powering flexibility.

Built Tough with All Metal Chassis
Dante Pro Dual Line Output is housed in an all-metal chassis for maximum ruggedness. And yes, we painted it Turtle Aqua so you know it looks cool even if mounted under a table where no one can see it.

Dante Ultimo
In networked audio, precision is essential, and Dante by Audinate delivers with unmatched synchronization and ultra-low latency performance. Leveraging advanced Precision Time Protocol (PTP), Dante ensures every audio packet arrives at exactly the right moment, maintaining audio quality and eliminating jitter, even in complex networks. Turtle AV adapters, powered by the genuine Dante Ultimo chipset, provide seamless compatibility and full interoperability with any Dante-compatible device, ensuring flawless, professional-grade sound for all installations, from live performances to intricate broadcast environments.

Easy Control
Take command with Dante Controller. Our adapters are fully controllable through this intuitive platform, allowing you to easily manage and adjust settings. With true plug-and-play functionality, your installation is up and running in no time, with no hassle.

100% Dante Software Compatible
Turtle AV Dante Adapters are fully compatible with Dante Controller, Dante Domain Manager, and all Dante software applications.

Audio Conversion
This adapter converts Dante 2CH digital audio into two-channel analog audio, supporting both balanced and unbalanced analog outputs. It offers a versatile Dante audio sampling rate of 44.1, 48, 88.2, and 96KHz at 24-bit, ensuring high-quality sound. The configurable Dante audio delay can be set to 1, 2, or 5 milliseconds, while the analog audio input features 3 levels of sensitivity adjustment, +18dBu, 0dBu, and -10dBV

AES67 Lives Here Too
Dante Pro Adapters support AES67 and Dante. Toggle between Dante and AES67 within Dante Controller.

  • Features:

    • Bi-directional conversion for two-channel USB audio and Dante 2CH digital audio
    • USB: Class Compliant USB 2.0 device
    • USB audio output up to 24bit/192KHz
    • USB audio input up to 24bit
    • Analog sound card, supporting MIC input and SPK output
    • Dante audio sampling rate supports 24bit 44.1/48/88.2/96KHz
    • Configurable Dante audio delay with support for 1, 2, or 5 milliseconds
    • Supports AES67 RTP audio transmission
    • PoE and 12V DC power via phoenix connector
    • Dante Ultimo Chipset
    • TAA compliant
    • Metal case for maximum ruggedness

  • Specifications:

      Technical
    • Input/Output: Interconverts between two-channel USB audio and Dante 2CH digital audio
    • USB Audio Class: 1.0/2.0-compatible
    • USB Audio Output: up to 192KHz@24bit
    • USB Audio Input: up to 96KHz@24bit
    • Control: Dante Controller
    • Audio Latency: Configurable Dante device latency (Supports 1, 2 or 5ms configurable using Dante Controller)
    • Audio Formats:
      - USB IN [Digital audio input, PCM 2CH 44.1K- 96KHz 16/24bit]
      - USB AUDIO OUT [Digital audio output, PCM 2CH 44.1K-192KHz 16/24bit]
      - DANTE IN/OUT [Digital audio output, PCM 2CH 44.1K-96KHz 16/24bit]
    • Audio Parameters:
      - Frequency Response: 20Hz to 20kHz (-/+0.5dB)
      - Dynamic Range: >100dB@0dBu, 1kHzA-weighted
      - Audio S/N Ratio: >100dB@0dBu, 1kHzA-weighted
      - Audio THD+N: < 0.01% at +4dBu, 1KHz
      - Audio Output Sync Delay: <10ms
    • ESD Protection: IEC 61000-4-2: ±8kV (Air-gap discharge) & ±4kV (Contact discharge)

      Connections
    • Input/Output:
      - 1x USB-C [USB-C with USB 1.0/2.0, USB audio in/out, 12-pin female]
      - 1x POWER [2-pin phoenix, 3.81mm]
      - 1x DANTE [RJ45 LAN, PoE]

      Mechanical
    • Housing: Metal enclosure
    • Color: Turtle Aqua
    • Dimensions: 4.72" x 1.85" x 1.02" (120mm x 47mm x 26mm)
    • Weight: 0.41lbs (188g)
    • Power Supply:
      - PoE: PoE IEEE802.3af Class 0
      - USB: 5V/500mA
    • Power Consumption: 2W (MAX)
    • Operating Temperature: 32°F - 104°F (-20°C - 60°C)
    • Relative Humidity: 20% - 90% RH (no condensing)

  • Item Includes:

    • 1x Turtle TAV-D2USB-PRO Dante Pro Dual Channel USB-B I/O Adapter

  • Warranty:

    • 3 Year Limited Warranty
