Tripp Lite SMART1500RMXLN 1500VA 1350W UPS Smart LCD Rackmount AVR 120V USB DB9 SNMP 2URM

ITEM #: TRL-S1500RMXLN MFG #: SMART1500RMXLN

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$1,989.00

Our Price:

$1,296.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


SMART1500RMXLN - Overview

Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for critical server, network and telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS) with built-in Auto-Voltage Regulation (AVR) actively corrects brownouts and overvoltages back to usable levels while maintaining a full battery charge in case of power failure. Tripp Lite's unique configuration excels in exceptionally poor-power environments with two separate levels of voltage boost to correct both slight undervoltages and severe brownout conditions. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Super-fast switchover from line to battery power occurs within milliseconds to maintain operation of connected equipment without interruption or reboot. 95% line-mode efficiency offers reduced heat emissions and operating costs. Network management interfaces support communications via USB, RS-232 and Pre-installed SNMPWEBCARD network interface. HID-compliant USB port enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment load levels, self-test data and utility power conditions. Includes PowerAlert monitoring software and complete cabling. Switched output load banks enable scheduled and real-time remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display panel easily rotates for viewing in rackmount or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode configuration options. Programmable self-test. Field-replaceable, hot-swappable battery modules.

  • Features:

    • Tripp Lite SMART1500RMXLN line interactive 2U rack/tower UPS with 1500VA / 1.5kVA / 1350W capacity and extended runtime options
    • Line interactive UPS with Automatic Voltage Regulation (AVR) corrects brownouts and overvoltages from 83 to 145V
    • NEMA 5-15P input plug; 8 NEMA 5-15R output receptacles, Two independently switched output load banks
    • Maintains uninterrupted operation of connected networking equipment during blackouts, surges, brownouts and overvoltages

  • Specifications:

    • Output Capacity Details Output derates to 1200 watts in all external battery configurations
    • Output Volt Amp Capacity (VA) 1500
    • Output kVA Capacity (kVA) 1.5
    • Output Watt Capacity (Watts) 1350
    • Output kW Capacity (kW) 1.35
    • Power Factor 0.9
    • Nominal Output Voltage(s) Supported 120V
    • Frequency Compatibility 60 Hz
    • Output Voltage Regulation (Line Mode) -14%, +6%
    • Output Voltage Regulation (Battery Mode) +/- 5%
    • Output Receptacles (8) 5-15R
    • Load Management Receptacles Two switchable two-outlet 5-15R load banks
    • Output AC Waveform (AC Mode) Sine wave
    • Output AC Waveform (Battery Mode) Pure Sine wave
    • Rated input current (Maximum Load) 12A
    • Nominal Input Voltage(s) Supported 120V AC
    • UPS Input Connection Type 5-15P
    • Input Circuit Breakers 15A
    • UPS Input Cord Length (ft.) 10
    • UPS Input Cord Length (m) 3
    • Recommended Electrical Service 15A 120V
    • Input Phase Single-Phase
    • Full Load Runtime (min.) 4.9 min. (1350w)
    • Half Load Runtime (min.) 14 min. (675w)
    • Expandable Battery Runtime Extended runtime supported via optional external battery packs
    • External Battery Pack Compatibility BP36V15-2U (limit 1); BP36V42-3U (multi-pack compatible); BP36V27-2US (multi-pack compatible)
    • DC System Voltage (VDC) 36
    • Battery Recharge Rate (Included Batteries) Less than 4.5 hours from 10% to 90% (typical, full load discharge)
    • Internal UPS Replacement Battery Cartridge RBC93-2U
    • Battery Access Front panel battery access door
    • Battery Replacement Description Hot-swappable, user replaceable batteries
    • Switches 3 pushbutton switches control OFF / ON power status, MODE selection and MUTE / ENTER control functions
    • Alarm Cancel Operation Power-fail alarm can be temporarily silenced using alarm-cancel switch; silent mode alarm configuration option available
    • Audible Alarm Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditions
    • UPS AC Suppression Joule Rating 570
    • UPS AC Suppression Response Time Instantaneous
    • EMI / RFI AC Noise Suppression Yes
    • Included Mounting Accessory Description 4 post rackmount installation accessories included
    • Installation Form Factors Supported with Optional Accessories 2 post rackmount (2POSTRMKITWM); Wallmount (2POSTRMKITWM); Tower (2-9USTAND); 2-4 post front rail rackmount (UPSHDEARKIT)
    • Primary Form Factor Rackmount
    • UPS Power Module Dimensions (hwd, in.) 3.45 x 17.3 x 13.45
    • UPS Power Module Dimensions (hwd, cm) 8.8 x 43.9 x 34.2
    • Rack Height (U Spaces) 2
    • UPS Power Module Weight (lbs.) 46.5
    • UPS Shipping Dimensions (hwd / in.) 8.5 x 23.4 x 19.9
    • Shipping Weight (lbs.) 51.3
    • Cooling Method Fan
    • UPS Housing Material Steel
    • AC Mode BTU / Hr. (Full Load) 237
    • AC Mode Efficiency Rating (100% Load) 0.95
    • Communications Interface DB9 Serial; EPO (emergency power off); Pre-installed network card; Slot for SNMP/Web interface; USB
    • Network Monitoring Port Description Includes Pre-installed SNMPWEBCARD network interface. Supports detailed monitoring of UPS and site power conditions
    • WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
    • Cold Start (Startup in Battery Mode During a Power Failure) Cold-start operation supported
    • High Availability UPS Features Hot swappable batteries
    • Green Energy-Saving Features Greater than 95% efficiency - GREEN UPS; Individually controllable load banks
    • UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI); ROHS (Restriction of Hazardous Substances)
    • Product Warranty Period (Worldwide) 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.
    • Connected Equipment Insurance (U.S., Canada & Puerto Rico) $250,000 Ultimate Lifetime Insurance

  • GTIN:

    0037332178022
