Magenta Research MG-FB-61X 4K HDMI 2.0 Fiber Extender Kit - 4K60 4:4:4 up to 300m (984ft)

ITEM #: TV1-MG-FB-61X MFG #: MG-FB-61X

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$3,310.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


MG-FB-61X - Overview

The Magenta Research MG-FB-61X magenta fiber optic transmitter and receiver kit is a powerful solution for extending uncompressed 4Kx2k 60Hz HDMI 2.0 signals over very long distances. The MG-FB-61x supports resolutions up to 4K60 4:4:4 with no compression and zero latency at distances up to 984ft (300m) using either single mode or multi-mode LC fiber. Support is also available for HDCP 2.2, HDR, bidirectional RS-232 and IR in addition to Audio Return Channel, CEC, and EDID pass through, making any installation simple. The Magenta fiber optic extender kit is completely secure and has industry leading RF and EMC immunity to ensure the highest levels of performance and signal integrity, while additionally providing the benefit of future proofing your installations.

  • Features:

    • Extends 4K60 uncompressed up to 984ft (300m)
    • Industry leading 5-year warranty
    • HDMI 2.0
    • HDCP 2.2 compliant
    • EDID & HDR support
    • Bi-directional IR and RS-232 pass-through
    • Audio Return Channel (ARC) using Toslink
    • Mounting ears included
    • Locking power supply connectors

  • Specifications:

    • Transmitter
    • Input: (1) HDMI IN
    • Input Connector: (1) Type-A female HDMI
    • Output: (2) OPTICAL OUT; (1) AUDIO OUT
    • Output Connector: (2) LC connector; (1) Toslink connector
    • Control: (1) IR IN; (1) IR OUT; (1) RS232
    • Control Connector: (2) 3.5mm mini jacks; (1) 3-pin terminal block

      Receiver
    • Input: (2) OPTICAL IN; (1) AUDIO IN
    • Input Connector: (2) LC connector; (1) Toslink connector
    • Output: (1) HDMI OUT
    • Output Connector: (1) Type-A female HDMI
    • Control: (1) IR IN; (1) IR OUT; (1) RS232
    • Control Connector: (2) 3.5mm mini jacks; (1) 3-pin terminal block

      General
    • Video Resolution: Up to 4Kx2K 60Hz 4:4:4 HDR
    • Bandwidth: 18Gbps
    • Color Depth: 16bpc (48bit/px)
    • Audio Format: PCM, Dolby Digital, DTS, DTS-HD
    • HDMI Standard: 2.0
    • HDCP Version: 2.2
    • CEC: Supported
    • EDID: Pass-through Supported
    • HPD: Supported
    • Transmission Distance: up to 984ft (300m) via single-mode or OM3/OM4 multi-mode fiber cables.
    • Operation Temperature: 14° to 131°F (-10° to 55°C)
    • Storage Temperature: -13° to 158°F (-25° to 70°C)
    • Humility: 10 to 90%
    • Power Supply Input: AC 100-240V, 50/60Hz; Output: 12VDC 1A.
    • Replacement: PSU PS-12-10-LK
    • Power Consumption: 9W (max)
    • Dimension (WxHxD): 5.12 x 0.79 x 3.31" (130 x 20 x 84mm)
    • Weight: 0.38Lbs (175g)

  • Warranty:

    • 5 Year Warranty
