West Penn 25226B 14/2 Plenum Speaker Cable - 500 Feet - Gray

ITEM #: WP-25226B-500 MFG #: 25226BGY0500

Primary Image
West Penn Wire Corp
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$228.10

Our Price:

$192.04

Add to Wish ListLeasing Options
Availability: In Stock
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

25226BGY0500 - Overview

West Penn 25226B Plenum Communication Cable, 14/2 Stranded Bare Copper Conductors, Unshielded with an Overall Jacket. Suitable indoor within ducts, plenums, and other spaces used for environmental air for (Intercom Systems, Security Systems, Sound, Audio, Background Music).

  • Specifications:

    • Conductor: 14 AWG Bare Copper
    • Stranding: 19x27
    • Insulation: Material Flex Plenum PVC
    • Insulation: Thickness 0.010" Nom.
    • Number of Conductors: 2
    • Shield: None
    • Drain: None
    • Jacket: Material Flex Plenum PVC
    • Jacket: Thickness 0.015" Nom.
    • Overall Cable Diameter: 0.218" Nom.
    • Approximate Cable Weight: 36 Lbs/1M' Nom.
    • Flame Rating: NFPA 262 Flame
    • Temperature Rating: -10°C To +60°C
    • Operating Voltage: 150 V RMS
    • Max.Capacitance: Between Conductors @ 1 KHz 34 pf/ft Nom.
    • DC Resistance per Conductor @ 20deg C: 2.7 Ohms/1M' Nom.
    • Insulation Colors: Black, Red
    • Jacket Color: Gray, Black
    • RoHS Compliant: Yes


  • GTIN:

    0612825045878
