West Penn 25440B 18 Awg 2 Pair Stranded Cable - Per Foot

Name: West Penn 25440B 18 Awg 2 Pair Stranded Cable - Per Foot
Brand: West Penn Wire Corp
SKU: WP-25440B
Price: 0.95 USD
Availability: InStock

ITEM #: WP-25440B MFG #: 25440B PER FOOT

West Penn Wire Corp

Our Price:

$0.95

Quantity Pricing

Add to Wish List Leasing Options

Availability: In Stock

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

25440B PER FOOT - Overview

West Penn 25440B is perfect for indoor within ducts, plenums, and other spaces used for environmental air for (Pro Audio, Intercom Systems, Security Systems, Sound, Background Music).

Specifications:
- Conductor: 18 AWG Bare Copper
- Stranding: 7x26
- Insulation Material: Flex Plenum PVC
- Insulation Thickness: 0.008'' Nom.
- Number of Conductors: 4 (2 Pairs)
- Shield: Individually 100% Aluminum Polyester Foil
- Drain: Stranded Tinned Copper Common to all shields
- Jacket Material: Flex Plenum PVC
- Jacket Thickness: 0.015'' Nom.
- Overall Cable Diameter: 0.253'' Nom.
- Approximate Cable Weight: 43 Lbs/1M' Nom.
- Flame Rating: NFPA 262 Flame Test
GTIN:
0612825049869
